A60 QUICK OPEN & CLOSE WEATHERTIGHT STEEL DOOR
262JY020 – 00
[Two diagrams: left is a front – view of the door with a handle and locking mechanism, labeled with dimensions B1XL1XR1 and BXL; right is a side – view showing the door’s structure and installation, labeled with B2XL2. A list of optional items on the right includes: bumper, door closer, C2 lock, ISPS device, limit switch, port light.]
| Size of Doorway BXL | Size of B.H. Opening B1XL1XR1 | Frame Size B2XL2 | Weight (KG) |
|---|---|---|---|
| 600X1650 | 700X1750X150 | 800X1850 | 220 |
| 700X1650 | 800X1750X150 | 900X1850 | 230 |
| 800X1800 | 900X1900X150 | 1000X2000 | 268 |
| 1200X2300 | 1300X2400X150 | 1400X2500 | 424 |
Note: The weight is calculated based on that T = 8mm.
Marking Example:
For a single – leaf A60 quick open & close weathertight steel door with a doorway size of 600X1650 and a door panel thickness of 8mm (left – outer opening type): A60 Quick Open & Close Weathertight Steel Door 600X1650 – 8 – 6.1 262JY020 – 00.
Attention please: The description might be incorrect, please contact us for confirmation.
