STEEL PRESSURE RESISTANT WATERTIGHT DOOR
The applicable water pressure for the door is no more than 0.15MPa.
[Diagram showing top-view and side-view of the steel pressure resistant watertight door. Top-view labels include: B2×L2×R2, B1×L1×R1, B×L×R. Side-view shows the door’s structure and installation. A table of optional items on the right lists: bumper, door closer, C2 lock, ISPS device, limit switch, port light.]
| Size of Doorway B×L×R | Size of B.H. Opening B1×L1×R1 | Outer Size B2×L2×R2 | Door Leaf Thickness T (mm) | Weight (KG) |
|---|---|---|---|---|
| 600×1500×100 | 700×1600×150 | 800×1700×200 | 8 | 206 |
| 600×1600×100 | 700×1700×150 | 800×1800×200 | 8 | 212 |
| 700×1500×100 | 800×1600×150 | 900×1700×200 | 8 | 227 |
| 700×1600×100 | 800×1700×150 | 900×1800×200 | 8 | 239 |
| 700×1700×100 | 800×1800×150 | 900×1900×200 | 8 | 250 |
| 800×1500×100 | 900×1600×150 | 1000×1700×200 | 8 | 248 |
| 800×1600×100 | 900×1700×150 | 1000×1800×200 | 8 | 263 |
| 800×1700×100 | 900×1800×150 | 1000×1900×200 | 8 | 289 |
Marking Example:
For a doorway size of 600×1500 and a door leaf thickness of 8mm steel pressure resistant watertight door (right-outer opening type), it is marked as: Steel pressure resistant watertight door 600×1500-8-5.1 262JY020-00.
Attention please: The description might be incorrect, please contact us for confirmation.
