A60 CLASS DOUBLE LEAVES FIREPROOF DOOR (WITH SMALL FIRE FIGHTING DOOR)
JY015S – 00
Diagram
The image contains a front – view diagram of the A60 double – leaf fireproof door with a small fire – fighting door, labeled with dimensions B1×L1, B×L, B2×L2, and a side – view diagram showing the door’s structure and installation details with a thickness dimension of 145mm. There are also three small diagrams indicating the suitable bulkhead types: A (one – layer steel bulkhead), B (one – layer steel bulkhead and one – layer decorative bulkhead), C (one – layer steel bulkhead and two – layer decorative bulkheads).
Table of Specifications
| Size of Doorway B×L | Frame Size B1×L1 | Size of B.H. Opening B2×L2 | Weight (KG) | Optional Items |
|---|---|---|---|---|
| 1200X1700 | 1294X1794 | 1300X1800 | 142 | Door closer, Door stopper, Fire – fighting small door, Hose port |
| 1300X1700 | 1394X1794 | 1400X1800 | 148 | |
| 1400X1700 | 1494X1794 | 1500X1800 | 154 | |
| 1100X1750 | 1194X1844 | 1200X1850 | 150 | |
| 1200X1750 | 1294X1844 | 1300X1850 | 157 | |
| 1300X1750 | 1394X1844 | 1400X1850 | 164 | |
| 1400X1750 | 1494X1844 | 1500X1850 | 171 | |
| 1550X1850 | 1644X1944 | 1650X1950 | 196 |
Notes
- Weight is calculated based on a door thickness of 90mm (at a diameter of 90mm).
- Marking example: For a 1200X1700 door with one – layer steel bulkhead and one – layer decorative bulkhead A60 double – leaf fireproof door: A60 – B – 1200X1700 JY015S – 00.
Attention please: The description may be different with the goods, please check with us when order.
