16A SHIP NYLON SWITCH
Main Parameters
| Item | Content |
|---|---|
| The scope of application | Used for connecting cutting on or off the appliance circuit with AC or DC low-voltage |
| Protection Class | IP56 |
| Cable outside diameter | φ14~φ16 |
| Housing Material | Nylon |
| Pole/Throw Illustration | Voltage | 24V | 125V | 250V | 500V | 500V |
|---|---|---|---|---|---|---|
| 1 Pole (1NO) | Code | 1133/F/5 | ||||
| Type | HS101-1 | HS101-2 | HS101-3 | HS101-4 | HS101-5 | |
| Weight | 0.22KG | 0.22KG | 0.22KG | 0.22kg | 0.22KG | |
| 2 Pole (2NO) | Code | 1133/D/F/5 | ||||
| Type | HS201-1 | HS201-2 | HS201-3 | HS201-4 | HS201-5 | |
| Weight | 0.23KG | 0.23KG | 0.23KG | 0.23kg | 0.23KG | |
| 3 Pole (3NO) | Code | 1133/2/F/5 | ||||
| Type | HS202-1 | HS202-2 | HS202-3 | HS202-4 | HS202-5 | |
| Weight | 0.23KG | 0.23KG | 0.23KG | 0.23kg | 0.23KG | |
| 1 Pole 1 Throw (1NO1NC) | Code | 1133/3/F/5 | ||||
| Type | HS302-1 | HS302-2 | HS302-3 | HS302-4 | HS302-5 | |
| Weight | 0.24KG | 0.24KG | 0.24KG | 0.24kg | 0.24KG | |
| 2 Pole 1 Throw (2NO1NC) | Code | 1133/2D/F/5 | ||||
| Type | HS402-1 | HS402-2 | HS402-3 | HS402-4 | HS402-5 | |
| Weight | 0.25KG | 0.25KG | 0.25KG | 0.25kg | 0.25KG |
Attention please: The description may be different with the product, please contact us for quotation.
