YWC Series Advanced 15PPM Oily Water Separator
The YWC Series Advanced 15PPM Oily Water Separator is a state-of-the-art, IMO-certified oil-water separation system tailored for both marine and industrial environments. Featuring 9 distinct capacity variants, spanning from 0.25 m³/h to 5 m³/h, this system is versatile enough to serve a wide range of vessels, from compact boats (<1000 DWT) to colossal tankers (>300,000 DWT). It ensures that the oil content in the effluent water remains at or below 15 ppm, strictly adhering to the IMO MEPC.107(49) regulations.
Key Attributes & Technical Specifications
✔ Diverse Capacity Options: Ranging from 0.25 m³/h to 5 m³/h, with 9 models to choose from
✔ Superior Oil Separation Efficiency: Maintains ≤15 ppm oil content in the discharged water
✔ IMO Certification: Fully compliant with MEPC.107(49) standards for maritime applications
✔ Heating Flexibility:
- Steam heating (ideal for high-viscosity oils)
- Electric heating (as an alternative heating solution)
✔ Accreditations: Endorsed by CCS & EC for quality and reliability
✔ Broad Application Scope: Perfect for ships of all sizes (1000 DWT – 300,000+ DWT) and industrial/oilfield settings
✔ Integrated OCM-15 Oil Content Monitoring Device: - Continuously measures oil concentration in real-time
- Guarantees automatic adherence to discharge regulations
PRODUCT DETAILS
Model: YWC-5.00
- Compressed Air Pressure (supplied by the vessel): 0.6-1.0MPa
- Heating Method: Electrical heating for efficient performance
- Oil Content Post-Treatment: ≤15ppm for clean discharge
- Discharge Water Pressure: 0.15MPa for optimal flow
- Separation Type: Vacuum-based for effective separation
- Back Flush Water Pressure (supplied by the vessel) and Cleaning Water Pressure: <0.3MPa for gentle yet thorough cleaning
- Treatment Capacity: 5.00m³/h for robust handling of oily water
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
