Marine Wooden Pilot Rope Ladder – Technical Specifications
Product Overview
The Mount Ship Rope Ladder (also called Embarkation Ladder) is a lightweight yet durable marine ladder designed for emergency evacuations and routine crew boarding during anchoring.
Compliance & Certification
✔ Manufacturing Standards:
-
CB/T 428-93 (China Shipbuilding Standard)
-
ISO 5489:1986 (International Standard)
✔ Certification: DNV Type-Approved
Wooden Pilot Rope Ladder Main Size List(mm):
| No of step | Weight (kg) | ||
| Aluminum | Wood | ||
| 10 | 25.86 | 3100 | 31.56 |
| 15 | 33.47 | 4650 | 43.92 |
| 20 | 41.08 | 6200 | 56.27 |
| 25 | 48.69 | 7750 | 68.64 |
| 30 | 56.3 | 9300 | 81 |
| 35 | 63.91 | 10850 | 93.36 |
| 40 | 71.52 | 12400 | 105.72 |
| 45 | 79.13 | 13950 | 118.08 |
| 50 | 86.74 | 15500 | 130.44 |
| 55 | 94.35 | 17000 | 142.86 |
| 60 | 101.96 | 18500 | 155.16 |
| to add each 5 steps | weight increase 7.61 | length increase 1500 | weight increase 12.36 |
The description/sizes may be different with goods, please check with us when order.
