Waterfall Hydraulic Winch – Advanced Dual-Drum Pulling Power
Innovative Engineering for Heavy Load Handling
The Waterfall Hydraulic Winch represents a breakthrough in winch technology, featuring a unique cascading hydraulic cylinder system that delivers exceptional power density and control precision. Designed for the most demanding lifting and pulling applications, its dual-drum configuration operates both simultaneously and independently, providing unmatched versatility in confined or challenging workspaces.
Key Applications
✔ Offshore Heavy Lifting – Platform installation & subsea equipment handling
✔ Marine Salvage Operations – Wreck recovery & heavy object retrieval
✔ Port & Shipyard Services – Dry-dock positioning & large component movement
✔ Specialized Construction – Bridge building & prefabricated structure placement
Technical Specifications
Proprietary Waterfall Hydraulic System
-
Cascading Cylinder Design – Generates 30% more power than conventional hydraulic winches
-
Intelligent Fluid Dynamics – Maintains consistent torque throughout operation
-
Dual-Pump Configuration – Ensures redundancy for critical operations
Dual-Drum Performance Features
✔ Independent or Synchronized Operation – Flexible load management
✔ Auto-Spooling Technology – Optional automatic rope alignment system
✔ Precision Control Interface – Micro-adjustment capability (±5cm accuracy)
Construction & Components
-
Marine-Grade Materials:
-
Stainless steel (corrosion-resistant components)
-
High-tensile carbon steel (load-bearing structures)
-
Aircraft-grade aluminum (lightweight housings)
-
Operational Advantages
-
Space-Optimized Design – 20% more compact than comparable capacity winches
-
Silent Operation – Advanced hydraulic damping (≤65dB at 1m)
-
Maintenance-Free Bearings – Sealed for 10,000+ hour service life
-
Smart Load Monitoring – Optional integrated weighing system (±1% accuracy)
Certifications & Quality Assurance
✔ CCS, BV, RINA Certified
✔ FEA-Validated structural integrity
✔ 500-Hour continuous operation testing protocol
Customization Options
-
Drum capacity (50-500kN standard, 1000kN+ available)
-
Control systems (local, remote, or automated PLC interface)
-
Special coatings (Arctic-grade, acid-resistant, or anti-fouling)
-
Safety systems (emergency disconnect, overload shear pins)
Parameters:
| Model | Holding load | Speed | Nominal Pulling Force | Length | Weight |
| kN | m/min | kN | m | ton | |
| YK-50 | 1000 | 10 | 500 | 36×1000 | 22 |
| YK-75 | 1450 | 9 | 750 | 44×1200 | 26 |
| YK-100 | 1800 | 6 | 1000 | 52×1400 | 32 |
| YK-125 | 2200 | 6 | 1250 | 56×1500 | 35 |
| YK-150 | 2650 | 5 | 1500 | 60×1600 | 40 |
| YK-175 | 3000 | 5 | 1750 | 64×1600 | 46 |
| YK-200 | 3200 | 5 | 2000 | 68×1600 | 52 |
The description/sizes may be different with goods, please check with us when order.
