DIN 81907 Warping Roller Fairlead with Pedestal – Precision German-Engineered Mooring Solution
Superior Rope Guidance with Stable Pedestal Base
Our DIN 81907 compliant Warping Roller Fairlead offers two professional-grade configurations:
✔ Type A – Cylindrical pedestal for balanced load distribution
✔ Type B – Conical pedestal for enhanced stability
Key Features & Benefits:
• Premium Construction – High-quality cast steel & steel plate
• Smooth Operation – Defect-free roller and pedestal surfaces
• Flexible Rope Guidance – Optimized for effortless mooring line handling
• Deck-Mounted Security – Stable installation for reliable performance
Technical Specifications:
-
Model: Warping Roller Fairlead with Pedestal
-
Materials: Marine-grade cast steel & steel plate
-
Standards: Fully compliant with DIN 81907 (German marine standard)
Parameters:
| Type | Weight | H | TUBE(DxS) |
| (kg) | |||
| 3 | 68 | 200 | 355.6X12.56 |
| 3 | 89 | 400 | 355.6X12.56 |
| 3 | 111 | 600 | 355.6X12.56 |
| 3 | 132 | 800 | 355.6X12.56 |
| 5 | 117 | 200 | 457.2X12.5 |
| 5 | 144 | 400 | 457.2X12.5 |
| 5 | 172 | 600 | 457.2X12.5 |
| 5 | 199 | 800 | 457.2X12.5 |
| 8 | 209 | 200 | 558.8X12.5 |
| 8 | 242 | 400 | 558.8X12.5 |
| 8 | 276 | 600 | 558.8X12.5 |
| 8 | 310 | 800 | 558.8X12.5 |
| 12 | 325 | 200 | 660.4X14.2 |
| 12 | 370 | 400 | 660.4X14.2 |
| 12 | 415 | 600 | 660.4X14.2 |
| 12 | 460 | 800 | 660.4X14.2 |
| 20 | 460 | 200 | 660.4X17.5 |
| 20 | 516 | 400 | 660.4X17.5 |
| 20 | 571 | 600 | 660.4X17.5 |
| 32 | 748 | 200 | 812.8X16 |
| 32 | 810 | 400 | 812.8X16 |
| 32 | 873 | 600 | 812.8X16 |
The description/sizes may be different with goods, please check with us when order.
