DA Type V Type Super Arch Marine Rubber Fender
When it comes to marine fender systems, the DA Type V Type Super Arch Marine Rubber Fender stands out as one of the most extensively utilized and highly efficient fender varieties available in the market. This advanced marine fender, also known as the super arch rubber fender, offers unparalleled performance in terms of energy absorption and structural stability, making it an ideal choice for protecting boats and ships at quays and docks.
Unmatched Energy Absorption and Cost Savings
The DA Type Super Arch Marine Rubber Fender is a new generation of V fenders, designed to provide 3-3.5% increased energy absorption compared to traditional models. This means that by opting for the super arch fender, you can significantly reduce the product height required, leading to substantial savings in project costs. When compared to other fender types, such as the cylinder type fender and the standard D type fender, the DA Type fender offers 3.5 times and 2.3 times higher unit weight energy absorption, respectively, while also consuming less material.
Enhanced Stability and Strong Attachment
One of the key advantages of the DA Type Super Arch Marine Rubber Fender is its superior stability and stronger attachment to the supporting structure. Unlike traditional arch rubber fenders, this model ensures a more secure and reliable connection, minimizing the risk of detachment or damage during berthing operations. This enhanced stability is particularly crucial in severe weather conditions or when dealing with large vessels, where the forces exerted on the fender can be substantial.
Durable and Long-Lasting Performance
The DA Type Super Arch Marine Rubber Fender is built to last. Its tough and reliable construction ensures trouble-free service for a wide variety of berthing scenarios, even under the most challenging conditions. The special structure design of the fender greatly improves stress concentration under compression deflection, thereby prolonging its service life significantly. This means that you can expect consistent and reliable performance from your DA Type fender for many years to come.
Easy Installation and Replacement
Another notable feature of the DA Type Super Arch Marine Rubber Fender is its ease of installation and replacement. The fender has the same bolt pitch as the V type fender, making it a straightforward upgrade option for those looking to enhance their existing fender systems. By simply replacing your V type fenders with DA Type fenders, you can achieve higher performance without the need for extensive modifications or additional hardware.
Detailed Specifications
Here are the detailed specifications for various sizes of the DA Type Super Arch Marine Rubber Fender:
| Dimensions (H×L) | H (mm) | L (mm) | L1 (mm) | a (mm) | Q (mm) | n | C (mm) | B (mm) | A (mm) | b (mm) | h (mm) | c (mm) | d (mm) | e (mm) | f (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 200×1000 | 200 | 1000 | 1100 | 120 | 860 | 1 | 130 | 320 | 400 | 128 | 30 | 58 | 105 | 29 | 75 |
| 200×1500 | 200 | 1500 | 1600 | 120 | 680 | 2 | – | – | – | – | – | – | – | – | – |
| 200×2000 | 200 | 2000 | 2100 | 120 | 620 | 3 | – | – | – | – | – | – | – | – | – |
| 200×2500 | 200 | 2500 | 2600 | 122.5 | 785 | 3 | – | – | – | – | – | – | – | – | – |
| 200×3000 | 200 | 3000 | 3100 | 120 | 715 | 4 | – | – | – | – | – | – | – | – | – |
| 200×3500 | 200 | 3500 | 3600 | 120 | 672 | 5 | – | – | – | – | – | – | – | – | – |
| 250×1000 | 250 | 1000 | 1125 | 130 | 865 | 1 | 164 | 410 | 500 | 160 | 64 | 125 | 32 | 90 | – |
| 250×1500 | 250 | 1500 | 1625 | 132.5 | 680 | 2 | – | – | – | – | – | – | – | – | – |
| 250×2000 | 250 | 2000 | 2125 | 132.5 | 620 | 3 | – | – | – | – | – | – | – | – | – |
| 250×2500 | 250 | 2500 | 2625 | 127.5 | 790 | 3 | – | – | – | – | – | – | – | – | – |
| 250×3000 | 250 | 3000 | 3125 | 132.5 | 715 | 4 | – | – | – | – | – | – | – | – | – |
| 250×3500 | 250 | 3500 | 3625 | 130 | 673 | 5 | – | – | – | – | – | – | – | – | – |
| 300×1000 | 300 | 1000 | 1150 | 140 | 870 | 1 | 225 | 490 | 600 | 195 | 33 | 70 | 140 | 35 | 105 |
| 300×1500 | 300 | 1500 | 16250 | 140 | 685 | 2 | – | – | – | – | – | – | – | – | – |
| 300×2000 | 300 | 2000 | 2150 | 137.5 | 625 | 3 | – | – | – | – | – | – | – | – | – |
| 300×2500 | 300 | 2500 | 2650 | 140 | 790 | 3 | – | – | – | – | – | – | – | – | – |
| 300×3000 | 300 | 3000 | 3150 | 145 | 715 | 4 | – | – | – | – | – | – | – | – | – |
| 300×3500 | 300 | 3500 | 3650 | 140 | 674 | 5 | – | – | – | – | – | – | – | – | – |
FAQs
Q1: What makes the DA Type Super Arch Marine Rubber Fender superior to other fender types?
A1: The DA Type fender offers unparalleled energy absorption, enhanced stability, and a stronger attachment to the supporting structure compared to traditional fender types. Its special structure design also prolongs its service life significantly.
Q2: Can the DA Type fender be easily installed and replaced?
A2: Yes, the DA Type fender has the same bolt pitch as the V type fender, making it easy to install and replace without the need for extensive modifications or additional hardware.
Q3: What are the cost savings associated with using the DA Type fender?
A3: By opting for the DA Type fender, you can reduce the product height required, leading to substantial savings in project costs. Additionally, its high energy absorption means less material is needed compared to other fender types.
Q4: Is the DA Type fender suitable for use in severe weather conditions?
A4: Absolutely. The DA Type fender is built to withstand even the most challenging conditions, providing reliable and trouble-free service for a wide variety of berthing scenarios.
Q5: How do I choose the right size of DA Type fender for my application?
A5: The size of the DA Type fender you need depends on various factors, including the size of your vessel, the expected forces during berthing, and the available space at your quay or dock. Our detailed specifications table can help you make an informed decision based on your specific requirements.
