UV Ballast Water Management System

UV Ballast Water Management System | USCG & IMO Approved | Chemical-Free BWMS for Marine Vessels

Product Overview
Our UV Ballast Water Management System (BWMS) is an advanced, environmentally responsible solution designed to prevent the spread of invasive aquatic species through ships’ ballast water. Utilizing proven medium-pressure ultraviolet disinfection technology, this system offers a safe, chemical-free method for treating ballast water that protects marine ecosystems without risking crew health or vessel safety. Certified by major international classification societies, it provides reliable compliance with IMO and USCG regulations across all sailing routes and water conditions.

Key System Components

1. MCC and PLC Control Panel

Fully automated operation with real-time monitoring
User-friendly interface for easy crew operation
Remote diagnostics and data logging capabilities

2. Medium-Pressure UV Reactor

Economy Mode: Automatically adjusts UV intensity based on water quality for reduced energy consumption
Performance Mode: Delivers maximum UV dosage for challenging water conditions
Scale Removal Sleeve: Automatic cleaning mechanism maintains optimal UV transmission
Temperature Monitoring: Ensures stable performance under varying conditions
Chemical-Free Operation: No toxic byproducts or hazardous substances

3. Automatic Self-Cleaning Filter

40-micron filtration removes sediments and organisms
Continuous operation during backflush cycles
Unique filter design ensures high removal efficiency
Minimizes sediment accumulation in ballast tanks
Reduces maintenance requirements and extends system life

Treatment Technology Comparison

Feature	UV Technology	Chlorine-Based	Ozone	Deoxygenation	AOP	Chemical Injection
Method	Physical	Chemical	Chemical	Asphyxiation	Chemical	Chemical
Pretreatment Required	Yes	Optional	Yes	Yes	Yes	Yes
Operation Cost	++	+	+++	+++	+++	+++
Maintenance Cost	+	++	+++	+	+++	+
Disinfection Performance	+++	+++	/	/	++++	++
Contact Time	0.1-0.3s	12-24h	15-30min	2-4d	12-24h	/
Toxic Chemicals	No	Yes	Yes	No	Yes	Yes
Immediate Discharge	Yes	No	No	No	No	No

System Operating Principles

Ballasting Process:

Ballast water enters through automatic filter, removing particles >40 microns
Filtered water passes through MPUV reactor for instant disinfection
UV-C radiation at 200-280nm wavelength destroys organisms’ DNA
Treated water flows to ballast tanks without sediment accumulation

De-ballasting Process:

Ballast water bypasses filter and flows directly to UV reactor
Secondary UV disinfection prevents regrowth during storage
Compliant discharge without environmental impact

Available Models & Capacities

Model	Treatment Capacity (m³/hr)	Voltage	Power Consumption
P-200	50-200	220±10V	27-36kW
P-300	200-300	220±10V	30-48kW
P-500	400-600	380±10V	48-72kW
P-750	600-800	380±10V	65-84kW
P-1000	800-1000	380±10V	75-108kW
P-1250	1000-1250	380±10V	103-132kW

Modular Combinations:

P-1500: 1500 m³/hr (P-750 × 2)
P-2000: 2000 m³/hr (P-1000 × 2)
P-3000: 3000 m³/hr (P-1000 × 3)
P-4000: 4000 m³/hr (P-1000 × 4)

Factors Affecting BWMS Selection

Vessel-Specific Considerations:

Large Bulk Carriers & Tankers: Require high-capacity systems for rapid ballasting/deballasting
Special Purpose Vessels: Must meet strict fire and explosion safety requirements
All Vessel Types: Chemical-free operation eliminates storage and handling risks

Route-Specific Considerations:

Variable Water Conditions: UV performance unaffected by salinity or temperature changes
High Turbidity Waters: Automatic filtration ensures consistent UV transmission
Stringent Port Requirements: Adjustable UV dosage meets higher local standards
Regional Routes: Immediate treatment eliminates holding time requirements
