China Tugboat Type Rubber Fender – Heavy-Duty Marine Protection System
Specially engineered for tugboats, push boats, and work vessels, our Tugboat Type Rubber Fender delivers superior impact absorption between vessels and docks. Typically installed on the bow, stern, and sides of towboats, this robust fender system effectively mitigates collision forces during pushing, towing, and berthing operations. By creating a protective barrier, it prevents damage to both the vessel and dock infrastructure, ensuring safer marine operations in ports, harbors, and inland waterways.
Featuring an integral one-piece structure, this rubber fender combines ease of installation with long-term durability, making it an ideal choice for commercial and industrial marine applications where impact resistance and reliability are critical.
Technical Specifications – Tugboat Rubber Fender
| ΦD (mm) | L (Length) | A (mm) | B max (mm) | C (mm) | E (Attachment Width) | ΦG (mm) | Φd (mm) | Φj (mm) |
|---|---|---|---|---|---|---|---|---|
| 200 | 2-13m per section or joined | 150 | 530 | 500 | Varies by attachment type | 150 | 100 | 75 |
| 250 | 2-13m per section or joined | 200 | 570 | 500 | Varies by attachment type | 190 | 125 | 75 |
| 300 | 2-13m per section or joined | 225 | 600 | 700 | Varies by attachment type | 225 | 150 | 75 |
| 350 | 2-13m per section or joined | 250 | 630 | 800 | Varies by attachment type | 260 | 175 | 100 |
| 400 | 2-13m per section or joined | 300 | 670 | 800 | Varies by attachment type | 300 | 200 | 100 |
| 500 | 2-13m per section or joined | 350 | 730 | 900 | Varies by attachment type | 375 | 250 | 100 |
| 600 | 2-13m per section or joined | 350 | 800 | 900 | Varies by attachment type | 450 | 300 | 125 |
| 700 | 2-13m per section or joined | 350 | 860 | 1000 | Varies by attachment type | 525 | 350 | 125 |
| 800 | 2-13m per section or joined | 350 | 930 | 1000 | Varies by attachment type | 600 | 400 | 125 |
| 900 | 2-13m per section or joined | 350 | 1000 | 1100 | Varies by attachment type | 675 | 450 | 150 |
| 1000 | 2-13m per section or joined | 350 | 1060 | 1200 | Varies by attachment type | 750 | 500 | 150 |
The description/sizes may be different with goods, please check with us when order.
