Tug Boat Rubber Fenders for Maximum Marine Protection
Product Overview
Our China-manufactured Tug Boat Rubber Fender is engineered to deliver superior impact absorption and lasting protection for all types of tugboats and workboats. Specifically designed for installation on the hull, these robust fenders safeguard your vessel and the assets it handles during critical operations like pushing, escorting, and berthing. Manufactured from high-grade, wear-resistant rubber compounds, they are built to withstand the harsh marine environment, including resistance to ozone, weathering, and seawater.
We offer a comprehensive range of standard sizes and types, including the popular A-B Type (Cone Type) and versatile B Type (Cylindrical Type), to meet the specific dimensional and performance requirements of any tugboat fleet.
Detailed Specifications
A-B Type (Cone Type) Fender Specifications
| A-B Norms And Size | a | P | n | b | C | D | D’ | d | d | L | I | I |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Φ500xΦ400xΦ250xΦ100x16000L | 500 | 1000 | 15 | 60 | 40 | 500 | 400 | 250 | 100 | 16000 | 450 | 1000 |
| Φ700xΦ600xΦ350xΦ100x14000L | 370 | 780 | 17 | 60 | 40 | 700 | 600 | 350 | 100 | 14000 | 450 | 1000 |
B Type Series (Cylindrical Type) Fender Specifications
| Norms And Size | b | C | ΦD | Φd | Φd’ | I |
|---|---|---|---|---|---|---|
| Φ300xΦ150xL | 50 | 25 | 300 | 150 | – | – |
| Φ300xΦ100xL | 50 | 25 | 300 | 100 | – | – |
| Φ400xΦ200xL | 50 | 35 | 400 | 200 | 300 | – |
| Φ400xΦ150xL | 50 | 35 | 400 | 150 | 100 | – |
| Φ400xΦ100xL | 50 | 35 | 400 | 100 | – | – |
| Φ500xΦ250xL | 60 | 40 | 500 | 250 | 350 | – |
| Φ500xΦ220xL | 60 | 40 | 500 | 220 | 100 | 350 |
| …(and the full range as provided) |
The description/sizes may be different with goods, please check with us when order.
