Single Point Mooring Pipe

China JIS F 2030-1978 A Type Single Point Mooring Pipe | Certified Marine Deck Fittings

Engineered to meet rigorous international standards, our JIS F 2030-1978 A Type Single Point Mooring Pipe provides a reliable and durable solution for guiding and securing mooring lines on commercial and naval vessels. As specialized panama chocks and essential deck fittings, these mooring pipes are designed for global maritime operations, ensuring safe and efficient mooring line management. We manufacture these critical components in a comprehensive range of sizes and styles to meet diverse vessel requirements.

Product Highlights & Key Features:

International Standard Compliance: Manufactured in strict accordance with JIS F 2030-1978 Type A specifications for guaranteed compatibility and performance.
Superior Rope Protection: Features smoothly finished internal surfaces to minimize rope abrasion and extend the service life of synthetic, steel wire, and natural fiber mooring lines.
Robust Material Construction: Fabricated from high-grade cast steel materials ZG200-400 and ZG230-450, ensuring exceptional strength and impact resistance.
Advanced Corrosion Protection: Standard finishes include Grey Epoxy Primer or Black Bitumen Paint, with custom coating thickness available upon request to suit specific environmental conditions.
Global Marine Certification: Officially certified by leading classification societies including BV, CCS, ABS, and DNV, with full mill certificates provided.
Secure Export Packaging: Supplied on sturdy steel pallets to ensure product integrity during international shipping and handling.

Detailed Technical Specifications:

Product No.	Nominal Size	Dimension L (mm)	Dimension L1 (mm)	Dimension H (mm)	Dimension H1 (mm)	Dimension B (mm)	Dimension C (mm)	Weight (KG)
SMA-001	400	400	780	300	680	350	65	400
SMA-002	500	500	940	400	840	400	70	500
SMA-003	600	600	1100	450	950	450	75	600
SMA-004	700	700	1260	500	1060	500	80	700
SMA-005	800	800	1420	600	1220	550	85	800
