Single Gypsy Windlass

92mm Electric Single Gypsy Windlass

Application

The 92mm Electric Single Gypsy Windlass is a heavy-duty anchoring system designed for large commercial vessels requiring robust anchor handling capabilities.

Primary Applications:

• Anchor management for Ø92mm chains

• Mooring operations via optional drum

• Tankers & bulk carriers

• Offshore support vessels

Key Features:
✔ High-capacity single gypsy for Ø92mm chains
✔ Integrated drum for mooring line handling
✔ Sealed gearbox (IP56) for maximum protection
✔ Manual brake/clutch for immediate control

---

Technical Specifications

Parameter	Specification
Chain Size	Ø92mm (ISO G4)
Motor Power	30-75kW (400V/50Hz)
Control Voltage	24V DC/110V AC
Pull Capacity	Up to 200kN
Gear Type	Helical gear (oil bath)

---

Construction & Materials

Main Components:

• Frame: High-grade cast steel (ASTM A148)

• Gypsy: 316L stainless steel (PREN >25)

• Gears: Case-hardened alloy steel (HRC 58-62)

---

Advantages & Features

1. Heavy-Duty Performance

   • Handles large anchor chains with ease

   • Continuous duty rating

2. Operational Control

   • Local control station (IP56 rated)

   • Optional bridge remote control

3. Maintenance Optimized

   • Centralized lubrication system

   • Easy-access service points

4. Safety Systems

   • Manual band brake with failsafe

   • Overload protection

5. Certifications

   • IRS, RINA, LR

   • SOLAS compliant

Parameters:

Chain Dia.(AM3)	Supporting Load	Working Speed	Working Load	Overload pull	Motor Power
mm	KN	m/min	KN	KN	kW
92	2735	≥9	402	603	130

The description/sizes may be different with goods, please check with us when order.
