JIS C3410 Shipboard Individual Screened Telephone Cable | IEC 60332 Flame Retardant Marine Instrumentation Cable | Explosion-Proof Vessel Communication & Alarm System Cable
Product Description:
Designed for critical marine communication and control applications, the JIS C3410 Shipboard Individual Screened Telephone Cable delivers reliable signal transmission and interference-free performance in both safe and hazardous areas onboard vessels. This certified cable is engineered for fixed installations within instrument circuits up to 250V, including communication, control, alarm, and safety systems. Each pair is individually screened to minimize crosstalk and electromagnetic interference (EMI), ensuring clear and secure telephone and data communication even in demanding maritime environments.
Constructed with tinned copper conductors, PVC insulation, and braided shielding—available in both galvanized steel and tinned copper armor options—this cable offers excellent corrosion resistance, mechanical durability, and flame retardancy. Compliant with JIS C3410 and international safety standards, it is ideal for use in naval, commercial, and offshore applications where reliability and safety are paramount.
Applications:
-
Shipboard telephone and intercom systems
-
Instrumentation and control circuits (up to 250V)
-
Alarm and safety systems in explosion-risk and safe areas
-
Fixed installation communication networks
-
General-purpose marine signaling and data transmission
Compliance & Standards:
-
Design Standard: JIS C3410 (1999)
-
Flame Retardancy: IEC 60332-1 & IEC 60332-3 Category A (FA-Type)
-
Low-Temperature Performance: CSA C22.2 No. 03 (-35°C Cold Bend/Impact Rating)
-
Max Conductor Temperature: 60°C
Available Models:
-
TTPY-S, TTPYC-S, TTPYCY-S (250V Rated)
-
TTY-S, FA-TTY-S (250V Rated)
-
TTYC-S, FA-TTYC-S (250V Rated)
-
TTYCY-S, FA-TTYCY-S (250V Rated)
Cable Construction:
| Component | Code | Description |
|---|---|---|
| Conductor | TT | Tinned Copper Wire (per JIS C3410) |
| Insulation | Y | PVC Insulation (per JIS C3410) |
| Individual Shield | -S | Tinned Copper Wire Braid |
| Armor | C | Galvanized Steel Wire Braid |
| Armor (Alternate) | CB | Tinned Copper Wire Braid |
| Outer Sheath | Y | PVC, Black (Uniform White Paint Marked) |
The description/sizes may be different with goods, please check with us when order.
