ZYG – 1.0 Ship Hydrophore Unit | 1.0m³ High – Capacity Fresh Water Pressure Vessel | DNV – GL Approved
The ZYG – 1.0 Ship Hydrophore is a top – notch 1.0 cubic meter fresh water pressure tank, meticulously engineered for marine fresh water systems. This class – approved hydrophore unit boasts a design pressure of 0.6 MPa and a working pressure of 0.5 MPa. It is an excellent choice for delivering a continuous and stable supply of pressurized fresh water to various areas on ships and offshore platforms, including crew quarters, kitchens, and sanitary facilities.
Key Features & Significant Advantages
✔ Safe for Drinking Water Consumption: The hydrophore unit features a non – toxic internal coating that has been rigorously certified for potable water use, ensuring the safety and purity of the fresh water supply for drinking purposes.
✔ Dual – Pump Redundancy System: Equipped with two redundant water pumps, this system guarantees uninterrupted operation. Even if one pump fails, the other can continue to function, providing a reliable source of pressurized fresh water.
✔ Highly Corrosion – Resistant Build: Constructed with SS304 piping and fittings, along with protective coatings, this hydrophore unit is highly resistant to corrosion. This extends its service life and ensures long – term performance in the harsh marine environment.
✔ All – Inclusive Safety Systems: It comes with a comprehensive set of safety features, including a pressure controller, a safety valve, and various monitoring instruments. These components work together to maintain safe operating conditions and prevent any potential hazards.
✔ Marine – Certified Design: Designed to meet the stringent requirements of DNV – GL, ABS, BV, and other well – known classification societies, this hydrophore unit is suitable for use on a wide range of marine vessels and offshore installations.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ZYG – 1.0 |
| Capacity | 1.0 m³ |
| Design Pressure | 0.6 MPa |
| Working Pressure | 0.5 MPa |
| Working Medium | Fresh Water |
| Structural Test Pressure | 0.9 MPa |
| Leak Test Pressure | 0.75 MPa |
| Electrical Protection | IP44 (Minimum) |
| Flange Standard | ANSI B16.5, RF#150 |
System Components & Premium Materials
Main Components List:
| No. | Component | Specification | Qty. | Material |
|---|---|---|---|---|
| 1 | Main Pressure Vessel | δ6 thickness | 1 | Q235B Steel |
| 2 | Liquid Level Gauge | ULG – 940H/A | 1 | Assembly |
| 3 | Instrument Valves | – | 2 | Assembly |
| 4 | Pressure Controller | KP35 | 1 | Assembly |
| 5 | Stop – Check Valve | B40010 GB596 | 1 | Copper |
| 6 | Pressure Gauge | YC – 100T | 1 | Assembly |
| 7 | Identification Nameplate | – | 1 | Stainless Steel |
| 8 | Safety Valve | A21F – 16P | 1 | Assembly |
| 9 | Electric Control Box | – | 1 | Assembly |
| 10 | Manhole Cover | DN400 | 1 | Assembly |
| 11 | Stop – Check Valves | B16040 GB591 – 93 | 2 | Assembly |
| 12 | Ball Valve | DN20 | 1 | Stainless Steel |
| 13 | Water Pumps | 1.5CWX – 3G | 2 | Cast Iron |
| 14 | Support Base | – | 1 | Q235A Steel |
The description/sizes may be different with goods, please check with us when order.
