58mm Heavy-Duty Ship Hydraulic Windlass
PRODUCT OVERVIEW
The 58mm Ship Hydraulic Windlass represents professional-grade deck machinery designed for heavy marine applications. Engineered for commercial vessels requiring superior anchoring performance, this robust system combines hydraulic efficiency with multi-functional capabilities for demanding maritime operations.
TECHNICAL SPECIFICATIONS
Core Configuration
-
Hydraulic motor drive system
-
58mm chain compatibility
-
Integrated drum winch functionality
-
Single warping head design
-
Closed gearbox (standard)
-
Manual brake & clutch system
Construction Materials
-
Main structure: Reinforced cast steel
-
Critical components: Marine-grade 316L stainless steel
KEY ADVANTAGES
✔ Dual-Function Design
-
Combines anchor handling and winch operations
-
Space-saving integrated solution
✔ Superior Engineering
-
Heavy-duty construction (58mm capacity)
-
Corrosion-resistant marine materials
✔ Operational Excellence
-
Dual control modes (local + remote)
-
Energy-efficient hydraulic operation
-
Simplified maintenance design
✔ Certified Performance
-
Compliant with IRS, BV, LR standards
-
Custom configurations available
| Main Technical Data Of Windlass | ||||||||||
| Chain Dia. | Capacity | Mooring speed | Working Load | Supporting Load | Working Speed | Warping Load | Drum cable diameter | Drum load | Drum support load | Motor Power |
| mm | m | m/min | KN | KN | m/min | KN | mm | KN | KN | kW |
| 58 | 220 | ≥9 | 143 | 816 | ≥9 | 60 | 28 | 80 | 480 | 45/45/30 |
The description/sizes may be different with goods, please check with us when order.
