58mm Ship Electric Combined Windlass
Application
The 58mm Ship Electric Combined Windlass is a professional-grade anchoring and mooring system designed for commercial vessels requiring heavy-duty chain handling and versatile rope work.
Primary Applications:
-
Anchor handling for Ø58mm chains
-
Mooring operations via integrated warping drum
-
Offshore supply vessels
-
Tugs & workboats
Key Features:
✔ Dual-function design: Gypsy + drum combination
✔ Sealed gearbox: IP56 protection against seawater
✔ Manual brake/clutch: Immediate operational control
✔ High-efficiency motor: 15-30kW power range
Technical Specifications
| Parameter | Specification |
|---|---|
| Chain Size | Ø58mm (ISO G3) |
| Drum Capacity | Ø32mm-50mm ropes |
| Motor Power | 15-30kW (400V/50Hz) |
| Control Voltage | 24V DC/110V AC |
| Gear Ratio | 150:1 (helical gear) |
Construction & Materials
Frame & Housing:
-
Cast Steel (ASTM A148 Grade 80-50)
-
Yield strength: 350MPa
Wear Components:
-
316L Stainless Steel (PREN >25)
-
Hardened alloy steel gears (HRC 58-62)
Advantages & Features
-
Hybrid Functionality
-
Dual gypsies for two-chain operation
-
Single drum for mooring lines
-
-
Control Systems
-
Local control panel (IP56)
-
Optional bridge remote
-
-
Maintenance Optimized
-
Centralized lubrication system
-
Quick-access gearbox
-
-
Safety Systems
-
Manual band brake (asbestos-free)
-
Overload protection switch
-
-
Certifications
-
IRS, BV, LR
-
SOLAS compliant
-
| Specifications | |
| Chain diameter(AM3) | 58mm |
| Support load | 300KN |
| Rope diameter | 60mm |
| Capacity | 200m |
| Power | 55KW |
| Working load | 159.8KN |
| Overload | 171KN |
| Support load | 182.6KN |
| Speed | ≥9m/min |
| Drum load | 100KN |
| Drum speed | ≥15m/min |
The description/sizes may be different with goods, please check with us when order.
