Ship Electric Anchor Capstan for Marine Applications
We specialize in providing both horizontally and vertically installed Ship Electric Anchor Capstan, designed to meet the diverse needs of the marine industry. Our capstans offer a wide line pull range, extending up to an impressive 200KN, ensuring robust performance in various anchoring scenarios. Additionally, we pride ourselves on offering tailored solutions to cater to specific customer requirements, enhancing the versatility and adaptability of our products.
Key Features of Vertical Electric Hydraulic Capstans:
- Integrated Safety Mechanisms: Our vertical electric hydraulic capstans are equipped with valve blocks that incorporate brake and overload protection functions, ensuring safe and reliable operation.
- Enhanced Drive Reliability: The inclusion of a valve block simplifies the design of the Hydraulic Power Unit (HPU), leading to improved drive reliability and reduced maintenance needs.
- High-Efficiency Performance: These marine vertical winches boast high startup and working efficiency, coupled with high power output and low noise levels, making them ideal for demanding marine environments.
- Compact Design: Our capstans feature a compact and space-saving design, allowing for easy installation and integration into existing ship and deck machinery.
Widespread Applications and Global Recognition:
Our electric hydraulic vertical capstans have gained widespread popularity in the marine industry, both domestically and internationally. Our products have been successfully exported to Southeast Asia, Korea, Maldives, Holland, New Zealand, Australia, and beyond, attesting to their quality and reliability.
Certifications and Compliance:
Our marine electric hydraulic vertical capstans are supplied with certificates from reputable classification societies, including CCS, ABS, DNV, BV, RINA, BKI, etc. These certifications ensure that our products meet international standards and regulations, providing peace of mind to our customers.
Technical Parameters:
| Chain Dia (mm) | Warping Load (KN) | Warping Speed (m/min) | Wire Dia. (mm) | Working Load (KN) | Working Speed (m/min) | Motor Power (kw) |
|---|---|---|---|---|---|---|
| Φ11/14 | 5 | ≥10 | Φ11 | 5.9/7.4 | ≥12 | 3/1.2 |
| Φ16/17.5 | 8 | ≥10 | Φ13 | 10.9/13.0 | ≥12 | 4.3/1.7 |
| Φ19/22 | 10 | ≥10 | Φ13 | 15.3/20.6 | ≥12 | 6/2.5 |
| Φ24/26 | 20 | ≥8.5 | Φ15 | 24.5/28.7 | ≥9 | 7.5/7.5/5 |
| Φ28/30 | 30 | ≥8.5 | Φ17.5 | 33.3/38.3 | ≥9 | 16/16/11 |
| Φ32/34/36 | 30 | ≥8.5 | Φ17.5 | 43.5/49.1/55.1 | ≥9 | 16/16/11 |
| Φ38/40/42 | 50 | ≥8.5 | Φ20.5 | 61.4/68.0/75.0 | ≥9 | 22/22/16 |
| Φ44/46/48 | 50 | ≥8 | Φ26 | 82.3/89.9/97.9 | ≥9 | 30/30/22 |
| Φ50/52/54 | 60 | ≥8 | Φ26 | 106.3/114.9/123.9 | ≥9 | 30/30/22 |
| Φ56/58/60 | 60 | ≥8 | Φ26 | 133.3/143/153 | ≥9 | 45/45/30 |
FAQs:
Q1: What types of installation options are available for the Ship Electric Anchor Capstan?
A1: We offer both horizontally and vertically installed Ship Electric Anchor Capstans to accommodate different ship and deck configurations.
Q2: How does the valve block enhance the safety and reliability of the vertical electric hydraulic capstan?
A2: The valve block incorporates brake and overload protection functions, simplifying the HPU design and improving drive reliability, thereby ensuring safe and efficient operation.
Q3: What certifications do your marine electric hydraulic vertical capstans come with?
A3: Our capstans are supplied with certificates from reputable classification societies, including CCS, ABS, DNV, BV, RINA, BKI, ensuring compliance with international standards.
Q4: Can you provide customized solutions for specific customer requirements?
A4: Yes, we pride ourselves on offering tailored solutions to meet specific customer needs, ensuring optimal performance and satisfaction.
Q5: What is the maximum line pull range of your Ship Electric Anchor Capstans?
A5: Our capstans offer a wide line pull range, extending up to 200KN, providing robust anchoring capabilities for various marine applications.
