SHAFT AND RUDDER ASSEMBLY
Ship’s Main Propulsion System—Shafting Diagram
PART LIST
表格
| No. | Part Name |
|---|---|
| 1 | Hub Cap |
| 2 | Hydraulic Nut |
| 3 | Propeller |
| 4 | Nut Cutter |
| 5 | Fishing net cover |
| 6 | After S/T Seal |
| 7 | Integral Stern Tube |
| 8 | Propeller Shaft |
| 9 | Before S/T Seal |
| 10 | Hydraulic Coupling |
| 11 | Hydraulic Supergrip Bolts |
| 12 | Intermediate Bearing |
| 13 | Intermediate Shaft |
| 14 | Hydraulic Supergrip Bolts |
| 15 | Main engine output flange |
PRODUCT DESCRIPTION
Our company can undertake the design and manufacturing of various types of ship shaft and rudder assembly.
Shaft system assembly includes intermediate shafts, propeller shafts, integral stern tubes, stern shaft seal, hydraulic couplings, propellers, propeller caps, fairwaters, intermediate bearings, hydraulic tight fitting bolts, hydraulic nuts, grounding devices and shafting brakes etc.
Rudder system assembly includes rudder blades, rudder tillers, rudder stocks, rudder pins, rudder sleeves, upper rudder carriers, hydraulic nuts, anti-jump devices etc.
Note: The description may be different with the product, please contact us for quotation.
