CB 3062 – 79 Nine – Rollers Fairlead Type E
The Nine – Rollers Fairlead (Type E) stands out as the pinnacle of high – capacity options within our comprehensive fairlead product line. It is specifically engineered to deliver impeccable rope guidance for a wide range of ropes, including steel wire ropes with diameters ranging from 19.5 to 68mm and nylon ropes with diameters from 36 to 100mm. This versatility makes it an ideal choice for various marine mooring applications, ensuring smooth and efficient operations.
Key Features That Set It Apart
- 9 Precision – Engineered Rollers: Each of the nine rollers is meticulously designed to minimize friction during rope movement. By reducing friction, they effectively prevent rope abrasion, which is crucial for extending the lifespan of the ropes and ensuring their reliable performance in demanding marine environments.
- Deck – Mounted Stability for Heavy – Duty Operations: The fairlead is designed for secure deck – mounting, providing a stable base for heavy – duty mooring tasks. This stability is essential for maintaining the integrity of the mooring system, especially when dealing with large vessels or harsh sea conditions.
- Customizable Configurations: We understand that different marine operations have unique requirements. That’s why our Nine – Roller Fairlead (Type E) is available in both standard and modified configurations. Whether you need specific dimensions or additional features, we can tailor the fairlead to meet your exact needs.
- Strict Compliance with CB 3062 – 79 and Marine Industry Standards: Manufactured in strict accordance with the CB 3062 – 79 standard and other relevant marine industry regulations, this fairlead guarantees high – quality construction and reliable performance. You can trust it to meet the most stringent safety and operational requirements.
Detailed Parameters for Precise Selection
| Steel Wire Dia. (mm) | Nylon Wire Dia. (mm) | Weight (kg) | E (mm) | F (mm) | D (mm) | d (mm) | L (mm) | L1 (mm) | L2 (mm) | L3 (mm) | B (mm) | B1 (mm) | B2 (mm) | H (mm) | H1 (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 19.5 | 36 | 302 | 200 | 150 | 100 | 40 – 0.5 | 944 | 716 | 300 | 844 | 324 | 194 | 108 | 508 | 250 |
| 22.5 | 40 | 464 | 200 | 150 | 120 | 50 – 0.5 | 1048 | 776 | 320 | 928 | 384 | 232 | 128 | 552 | 270 |
| 26 | 45 | 596 | 200 | 180 | 130 | 55 – 0.5 | 1106 | 810 | 330 | 976 | 415 | 250 | 138 | 606 | 310 |
| 32 | 70 | 883 | 220 | 180 | 150 | 65 – 0.5 | 1250 | 910 | 370 | 1100 | 475 | 288 | 158 | 670 | 330 |
| 34.5 | 80 | 1048 | 240 | 200 | 160 | 70 – 0.5 | 1340 | 980 | 400 | 1180 | 507 | 308 | 168 | 710 | 360 |
| 37.5 | 85 | 1229 | 240 | 200 | 180 | 80 – 0.5 | 1450 | 1040 | 420 | 1270 | 571 | 345 | 190 | 7780 (should be 778) | 380 |
| 43 | 95 | 1911 | 260 | 210 | 200 | 90 – 0.5 | 1596 | 1146 | 460 | 1396 | 632 | 385 | 210 | 820 | 410 |
| 52 | 100 | 2675 | 260 | 220 | 230 | 100 – 0.5 | 1746 | 1236 | 490 | 1516 | 723 | 445 | 240 | 910 | 450 |
| 60.5 | – | 3887 | 300 | 240 | 260 | 120 – 0.5 | 1990 | 1410 | 560 | 1730 | 815 | 500 | 270 | 1000 | 500 |
| 68 | – | 6432 | 320 | 250 | 320 | 150 – 0.5 | 2330 | 1630 | 640 | 2010 | 997 | 620 | 330 | 1130 | 570 |
The description/sizes may be different with goods, please check with us when order.
