Marine Wire
Marine Wire Flat Triplex Electrical Cable stands out as the most durable and long – lasting option in the market for marine applications. This top – notch cable goes above and beyond the requirements set by UL 1426, ABYC, and the US Coast Guard Charter boat (CFR Title 46) standards, ensuring unparalleled safety and reliability on the water.
Crafted with high – end vinyl insulation, this marine electrical cable is rated to handle 600V of electrical pressure. It can withstand dry conditions up to 105° C and wet conditions up to 75° C. What’s more, it remains highly flexible even when exposed to extremely cold temperatures, as low as -40° F (-40° C), making it ideal for use in all kinds of marine environments, from frigid polar regions to colder coastal waters.
Features
- Ultra – Premium Flexible Tinned Copper Stranding (Type 3): This cable features the highest – quality ultra – flexible Type 3 tinned copper stranding. The tinned copper offers maximum protection against corrosion and electrolysis, which are common issues in marine settings. Additionally, it resists fatigue caused by constant vibration and flexing, ensuring long – term performance and reliability.
- Compliance with Stringent Standards: It surpasses the rigorous UL 1426, ABYC, and US Coast Guard Charter boat (CFR Title 46) standards. This means it meets or exceeds the safety and performance requirements for marine electrical systems, giving you peace of mind when using it on your boat.
- Cold – Weather Flexibility: One of its standout features is its ability to stay flexible even in extreme cold conditions (-40° F/C). This flexibility makes installation and handling much easier, regardless of the temperature, and ensures that the cable functions properly in all weather conditions.
- Resistance to Multiple Elements: This marine – grade cable is highly resistant to a wide range of harsh elements. It can withstand salt water, which is ubiquitous in marine environments, as well as battery acid, oil, gasoline, heat, abrasion, and ultra – violet radiation. This multi – element resistance ensures that the cable remains intact and functional over an extended period, even in the most challenging conditions.
- High – Quality Vinyl Insulation Specifications: The cable is constructed with premium vinyl insulation that has the following ratings:
- Voltage Rating: It can handle up to 600V, making it suitable for a variety of marine electrical applications.
- Dry Temperature Rating: The insulation can withstand dry temperatures up to 105° C, ensuring safety in high – temperature environments on board.
- Wet Temperature Rating: It can also function reliably in wet conditions at temperatures up to 75° C, which is common in marine settings.
Specifications
- Wire Colors: The cable comes with three distinct wire colors – black, white, and green. These colors are standard in marine electrical systems and help with easy identification and wiring.
- Wire Material: It is made of tinned copper, which provides excellent electrical conductivity while offering protection against corrosion and other environmental factors.
- Certification: This cable exceeds the UL 1426 standards specifically for marine pleasure craft, ensuring that it meets the highest safety and performance requirements for recreational boating applications.
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
