Marine Swivel Anchor Fairlead

AF-38 Marine Swivel Anchor Fairlead | Heavy-Duty Guide System for Reliable Anchoring

The AF-38 Marine Swivel Anchor Fairlead is engineered to deliver unmatched reliability and performance for commercial and recreational vessels. This heavy-duty fairlead ensures smooth wire rope guidance, reducing wear and extending the lifespan of your anchoring system. With a focus on rapid delivery and adaptable manufacturing, we provide both standard models and fully customized solutions tailored to your specific deck layout and operational requirements.

Product Highlights & Key Features:

Superior Build Quality: Precision-manufactured for reliable performance in harsh marine environments
Rapid Order Fulfillment: Consistently fast delivery times to keep your projects on schedule
Exceptional Durability: Robust construction ensures a long operational lifetime with minimal maintenance
Custom Engineering Solutions: Fully customizable designs based on your specifications, drawings, or sample products
Complete Product Range: We supply all types of marine fairleads for various vessel types and applications
Heavy-Duty Swivel Design: Ensures optimal rope alignment and reduces torsional stress on wire ropes

Technical Specifications:

Wire Rope Diameter	Sheave Diameter	Key Dimensions (mm)	Weight
mm	inch	mm	A	B	C	T	H	G	kg
25	1″	254	559	356	679	20	292	90	420
32	1-1/4″	305	711	508	889	30	343	100	720
38	1-1/2″	406	762	762	1296	40	459	150	1080
44	1-3/4″	508	1067	914	1568	50	546	190	2260
50	2″	610	1219	1067	1893	50	648	220	2480
64	2-1/2″	762	1372	1219	2127	60	800	250	2900
