Marine Screw Air Compressors
Our marine screw air compressors deliver exceptional performance for all your shipboard compressed air needs. Designed for continuous duty operation, these energy-efficient compressors provide clean, dry air for various marine systems while requiring minimal maintenance.
Key Features & Benefits:
✔ Space-Saving Design: Compact footprint ideal for tight engine rooms
✔ Quiet Operation: Low-noise performance enhances crew comfort
✔ Advanced Protection: Built-in pressure, temperature, and overload safeguards
✔ Global Compatibility: Standard 380V/50Hz & 440V/60Hz voltage options
✔ Complete Air Treatment: Optional filters, dryers, and regulators for air purity
Technical Specifications
Performance Data:
| Model | Pressure (MPa) | Capacity (m³/h) | Power (kW) | Cooling | Weight (kg) | Dimensions (mm) |
|---|---|---|---|---|---|---|
| HS105-AC101 | 0.7 | 1.4 | 11 | Air Cooled | 720 | 1130×890×1170 |
| HS105-AC102 | 0.8 | 1.7 | 15 | Air Cooled | 740 | 1130×890×1170 |
| HS105-AC103 | 1.0 | 1.4 | 15 | Air Cooled | 740 | 1130×890×1170 |
| HS105-AC109 | 0.8 | 3.8 | 30 | Air Cooled | 950 | 1180×1100×1470 |
| HS105-AC115 | 1.0 | 5.5 | 45 | Air Cooled | 1050 | 1180×1100×1470 |
Note: The description might be incorrect, please contact us for confirmation.
