Marine 0-60 MPA Pressure Gauge: Heavy-Duty & Corrosion-Resistant for Harsh Environments
Ensure the safety and performance of your vessel’s critical systems with our rugged Marine 0-60 MPA Pressure Gauge. Engineered specifically for the maritime industry, this high-pressure gauge delivers reliable monitoring for hydraulic, pneumatic, and compressed air systems, even in the most demanding offshore and marine conditions.
Product Overview & Key Features
-
Robust Marine-Grade Construction
Built with corrosion-resistant 316 stainless steel or 304 stainless steel cases and internals, this gauge is designed to withstand saltwater spray, high humidity, and corrosive marine atmospheres. Its IP64 protection rating ensures excellent resistance against water and dust ingress. -
High-Precision Measurement
Accurately monitor pressures from 0 to 60 MPA (Megapascals) with a class 1.6 or 1.0 accuracy rating (depending on model size). The clear, legible dial with a precision pointer allows for quick and easy reading, essential for marine hydraulic system monitoring and safety checks. -
Superior Vibration & Pulsation Resistance
The liquid-filled case option (Model V.H.4) dramatically dampens pointer flutter and protects internal mechanisms from damage caused by engine vibration and pulsating pressures. This anti-vibration marine pressure gauge ensures steady readings and an extended service life in high-vibration environments. -
Wide Operational Temperature Range
Performance guaranteed in extreme conditions, with an operating temperature range of -25°C to 70°C for liquid-filled models and -40°C to 70°C for dry models. Minimal temperature influence (≤0.4%/10°C) ensures consistent accuracy. -
Versatile Connection & Mounting Options
Available in standard sizes (Φ60mm, Φ75mm, Φ100mm, Φ150mm) with a variety of international thread connections including M14x1.5, G1/2″, G3/8″, and NPT 1/2″, ensuring easy integration into existing shipboard systems.
Comprehensive Model Variants for Every Application
Our marine pressure gauge series includes specialized models to meet diverse operational needs:
-
YC Series: Standard Marine Pressure Gauge – The go-to choice for general shipboard pressure monitoring.
-
Anti-Vibration Type (N) – Ideal for mounting on engines, pumps, and compressors.
-
YX Series: Pressure Gauge with Electric Contact – Allows for automated alarm triggering and system shutdowns at preset pressure levels.
-
YZ Series: Vacuum Pressure Gauge – For combined vacuum and pressure measurements.
-
Z Series: Vacuum Gauge – Dedicated to vacuum system monitoring.
-
YA Series: Ammonia Gauge – Compatible with ammonia-based refrigeration systems.
Technical Specifications at a Glance
| Size (mm) | Measure Range (MPa) | Accuracy | Connection Thread | Material |
|---|---|---|---|---|
| Φ60, Φ75, Φ100, Φ150 | Vacuum: -0.1~0 / Pressure: 0~60 | 1.6 / 1.0 | M14x1.5, G1/2″, NPT1/2″, more | 304, 316, 316L SS |
| Environmental Temp. | Vibration Resistance | Protection | Temperature Influence | |
| -25°C to 70°C (Liquid-Filled) | V.H.4 (Liquid-Filled) | IP64 | ≤ 0.4% / 10°C | |
| -40°C to 70°C (Dry) | V.H.3 (Dry) |
The description/sizes may be different with goods, please check with us when order.
