Marine Power Cable – RG6 Armoured Coaxial Cable for Marine Applications
Our RG6 75Ω armoured power cable is meticulously engineered for installation onboard ships and within various indoor marine environments. This high-performance marine cable meets rigorous international standards, ensuring reliable and safe signal transmission in the most demanding marine settings.
Key Applications & Long-Tail Keywords:
- Marine Coaxial Cable: Specifically designed for marine applications, providing robust signal transmission on ships and boats.
- RG6 Armoured Cable: Features durable armour for enhanced protection against physical damage and environmental factors.
- 75Ω Coaxial Cable for Marine Use: Ideal for transmitting video, audio, and data signals with minimal loss in marine environments.
- Indoor Marine Cabling Solutions: Suitable for a wide range of indoor marine applications, ensuring reliable connectivity.
Additional Long-Tail Keywords:
- Marine-grade RG6 coaxial cable
- Armoured coaxial cable for ships
- 75 ohm marine power cable
- Low smoke halogen-free marine cable
- High-performance marine coaxial solution
Compliance with International Standards:
- IEC 60092-350
- IEC 60332-3-22
- IEC 60754-1,2
- IEC 61034-1,2
- NEK 606:2004
Construction Details:
- Conductors: 18AWG solid bare copper for efficient signal transmission.
- Insulation: Foam PE for excellent electrical properties and durability.
- Shielding1: Al/Polyester/Al tape for effective electromagnetic interference (EMI) protection.
- Shielding2: Tinned copper braid for additional shielding and corrosion resistance.
- Bedding: Low smoke and halogen-free polyolefin, colored black, for safety and environmental compliance.
- Armour: Copper wire braid for robust physical protection.
- Outer Sheath: Low smoke and halogen-free polyolefin for enhanced durability and safety.
Technical Data:
- AWG: 18
- Nominal Conductor Diameter: 1mm
- Impedance: 75±5Ω
- Nominal Attenuation:
- @100MHz: 6.9 dB/100m
- @200MHz: 9 dB/100m
- @300MHz: 11.8 dB/100m
- @400MHz: 13.1 dB/100m
- @500MHz: 15.4 dB/100m
- @900MHz: 21.5 dB/100m
- @1700MHz: 29.4 dB/100m
- Capacitance: 53.5 pF/m
- Velocity of Propagation: 83%
- Conductor DCR: 21.4 Ω/km
- Shield DCR: 7.5 Ω/km
- Inductance: 0.32 μH/m
- Time Delay: 4 ns/m
Mechanical and Thermal Properties:
- Bending Radius: 15×OD
- Temperature Range: -30℃ ~ +75℃
Dimensions and Weight:
- Nominal Inner Conductor Diameter: 1.0mm
- Nominal Insulation Thickness: 1.8mm
- Nominal Sheath Thickness: 1.2mm
- Nominal Overall Diameter: 11.2mm
- Nominal Weight: 208 kg/km
FAQs:
Q1: What makes this RG6 armoured coaxial cable suitable for marine applications?
A1: This cable is specifically designed with marine-grade materials, including low smoke and halogen-free polyolefin bedding and outer sheath, as well as copper wire braid armour for enhanced physical protection and corrosion resistance, making it ideal for marine environments.
Q2: Does this cable comply with international marine standards?
A2: Yes, our RG6 armoured coaxial cable meets several international standards, including IEC 60092-350, IEC 60332-3-22, IEC 60754-1,2, IEC 61034-1,2, and NEK 606:2004, ensuring its reliability and safety in marine applications.
Q3: What is the maximum operating temperature of this cable?
A3: The cable can operate within a temperature range of -30℃ to +75℃, making it suitable for various marine climates and conditions.
Q4: How does the double shielding design enhance the cable’s performance?
A4: The double shielding design, consisting of Al/Polyester/Al tape and tinned copper braid, provides effective protection against electromagnetic interference (EMI), ensuring clear and reliable signal transmission even in noisy environments.
Q5: What is the bending radius of this cable, and why is it important?
A5: The bending radius of this cable is 15 times its outer diameter (OD). This specification is important as it indicates the minimum radius the cable can be bent without causing damage or affecting its performance, ensuring flexibility during installation.
