Marine Porthole Window – Technical Specifications
Product Overview
Marine Porthole Window Brass are designed for seagoing vessels, naval ships, and inland watercraft, combining classic aesthetics with marine-grade durability.
Parameters:
| Product No. | h | Clips Qty. | Opening Size | Clearlight Size(D) | D1 | d (Minimum) | |
| Deadlight | Frame | ||||||
| CQYS120-SS041 | 155 | 2 | 3 | 253 | 200 | 250 | 75 |
| CQYS120-SS042 | 182 | 2 | 3 | 308 | 250 | 305 | 75 |
| CQYS120-SS043 | 207 | 2 | 3 | 363 | 300 | 360 | 75 |
| CQYS120-SS044 | 232 | 3 | 3 | 413 | 350 | 410 | 75 |
| CQYS120-SS045 | 257 | 3 | 3 | 463 | 400 | 460 | 75 |
| CQYS120-SS046 | 282 | 3 | 4 | 513 | 450 | 510 | 75 |
The description/sizes may be different with goods, please check with us when order.
