Marine Water-tight Plug
Our Marine Water-tight Plug is a high-performance sealing solution specifically designed for marine electrical connections. Crafted from synthetic resin, this plug ensures reliable and watertight connections, even in harsh maritime environments. It conforms to JISF8832 and JISF8833 standards, guaranteeing its quality and suitability for marine applications. With an IP56 protection class, it offers excellent protection against dust ingress and water jets, making it an ideal choice for ships, boats, and other marine vessels.
Key Features:
- High-Quality Material: Made from synthetic resin, ensuring durability and resistance to corrosion and wear.
- IP56 Protection Class: Provides robust protection against dust and water, ensuring reliable performance in challenging conditions.
- Compliance with Standards: Conforms to JISF8832 and JISF8833 standards, ensuring compatibility and safety in marine applications.
- Versatile Specifications: Available in multiple types and specifications to meet diverse voltage, current, and cable diameter requirements.
Technical Parameters:
- Material: Synthetic resin
- Protection Class: IP56
- Compliance Standards: JISF8832, JISF8833
Specifications:
Type T-1MA
- International Code: 792801
- Voltage: 250V
- Current: 20A
- Cable Outside Diameter: Φ10-φ11
Type T-2MA
- International Code: 792803
- Voltage: 250V
- Current: 20A
- Cable Outside Diameter: φ14-φ16
Type T-MA
- Voltage: 24V
- Current: 10A
- Cable Outside Diameter: φ10-φ11
Type T-1MB
- International Code: 792802
- Voltage: 250V
- Current: 20A
- Cable Outside Diameter: φ10-φ11
Type T-2MB
- International Code: 792804
- Voltage: 250V
- Current: 20A
- Cable Outside Diameter: φ14-φ16
Type T-MB
- Voltage: 24V
- Current: 10A
- Cable Outside Diameter: φ10-φ11
(Note: Drawings of each type of Marine Water-tight Plug are available upon request, providing detailed visual representations of the product’s design and dimensions.)
FAQs:
- Q: What is the primary function of a Marine Water-tight Plug?
- A: The primary function of a Marine Water-tight Plug is to provide a reliable and watertight seal for electrical connections on marine vessels, ensuring safety and preventing damage from water ingress.
- Q: What materials are used in the construction of the Marine Water-tight Plug?
- A: The Marine Water-tight Plug is made from synthetic resin, a durable and corrosion-resistant material suitable for marine environments.
- Q: What is the protection class of the Marine Water-tight Plug, and what does it mean?
- A: The Marine Water-tight Plug has an IP56 protection class, which means it is well-protected against dust ingress and water jets, making it suitable for harsh maritime conditions.
- Q: How do I choose the right type of Marine Water-tight Plug for my application?
- A: Choose the type based on your specific voltage, current, and cable diameter requirements. Refer to the specifications table provided to find the most suitable model for your needs.
- Q: Are the Marine Water-tight Plugs compliant with international standards?
- A: Yes, our Marine Water-tight Plugs conform to JISF8832 and JISF8833 standards, ensuring their quality and suitability for marine applications worldwide.
Please Note: The description might be incorrect, please contact us for confirmation.
