Horizontal Marine Oil-Fired Boiler
Our marine oil-fired boiler is engineered with an ample heating surface reserve capacity. This design ensures consistent and reliable performance under both full-load and overload conditions, making it ideal for demanding marine environments.
High-Performance European Combustion Technology
The boiler is equipped with top-tier European-brand burners that offer:
- Precise proportional control for optimal fuel usage
- Programmed ignition sequences for safe and efficient startups
- Automatic purge cycles to maintain clean combustion
- Flame failure protection for enhanced operational safety
These features contribute to an outstanding combustion efficiency of over 99.5%, reducing fuel consumption and emissions.
Optimized Combustion Chamber Geometry
The boiler’s combustion chamber is designed with a contoured furnace shape that perfectly aligns with flame patterns. This prevents direct flame impingement on heating surfaces, extending equipment lifespan and improving efficiency.
Safe and Efficient Rear Flue Design
Our rear flue design maintains low temperatures in the flue chamber, enhancing operator safety and comfort during maintenance and inspections.
Superior Thermal Insulation Solutions
The boiler utilizes lightweight aluminum silicate fiber insulation, which provides:
- Excellent heat retention capabilities
- Minimal thermal energy loss
- Maximum operational efficiency for cost savings
Dual-Mode Control System for Enhanced Flexibility
The fully automated control panel offers:
- One-touch ignition and shutdown for ease of use
- Manual override capability for emergency situations
- Comprehensive safety monitoring systems for peace of mind
Complete Safety Protection Mechanisms
Integrated safety systems include:
- Automatic pre-purge cycles to clear residual gases
- Gas leak detection alarms for early warning
- Operational safety interlocks to prevent unauthorized use
- Flame failure protection to avoid unsafe conditions
- Fuel pressure safeguards to maintain consistent operation
Explosion-Proof Design for Added Security
The boiler incorporates dedicated explosion-proof safety gates to prevent potential hazards, ensuring a secure working environment.
Streamlined Installation Process for Marine Vessels
Our marine oil-fired boiler comes for protection during transit. Final assembly and commissioning are performed onsite, minimizing downtime and ensuring optimal performance from the start.
Marine Oil-Fired Boiler Technical Specifications:
| Model | Rated Steam Temperature (°C) | Feed Water Temperature (°C) | Heating Area (m²) | Rated Evaporation Capacity (t/h) | Rated Steam Pressure (MPa) | Furnace Volume (m³) | Fuel Consumption (m³/h) | Flue Gas Temperature (°C) | Max Transport Weight (t) |
|---|---|---|---|---|---|---|---|---|---|
| WNS1-0.7-Q | 170 | 20 | 21.52 | 1 | 0.7 | 0.74 | 81 | 157 | 4.9 |
| WNS1-1.0-Q | 184 | 20 | 21.52 | 1 | 1 | 0.74 | 82 | 165 | 4.9 |
| WNS2-0.7-Q | 170 | 20 | 49.72 | 2 | 0.7 | 1.47 | 162 | 158 | 8.4 |
| WNS2-1.0-Q | 184 | 20 | 49.72 | 2 | 1 | 1.47 | 162 | 138 | 8.4 |
| WNS2-1.25-Q | 193 | 20 | 49.72 | 2 | 1.25 | 1.47 | 162 | 144 | 8.4 |
| WNS3-1.25-Q | 193 | 20 | 71.86 | 3 | 1.25 | 2.16 | 246 | 163 | 10.3 |
| WNS4-1.0-Q | 184 | 20 | 99.62 | 4 | 1 | 2.85 | 323 | 158 | 12.3 |
| WNS4-1.25-Q | 193 | 20 | 99.62 | 4 | 1.25 | 2.85 | 323 | 160 | 12.3 |
| WNS4-1.6-Q | 204 | 20 | 99.62 | 4 | 1.6 | 2.85 | 324 | 167 | 12.3 |
| WNS6-1.0-Q | 184 | 105 | 149.22 | 6 | 1 | 3.89 | 418 | 152 | 15.1 |
| WNS6-1.25-Q | 193 | 105 | 149.22 | 6 | 1.25 | 3.89 | 419 | 167 | 15.1 |
| WNS6-1.6-Q | 204 | 105 | 149.22 | 6 | 1.6 | 3.89 | 420 | 167 | 15.1 |
| WNS8-1.0-Q | 184 | 105 | 186.33 | 8 | 1 | 5.1 | 556 | 155 | 20.3 |
| WNS8-1.25-Q | 193 | 105 | 186.33 | 8 | 1.25 | 5.1 | 560 | 165 | 20.3 |
| WNS8-1.6-Q | 204 | 105 | 186.33 | 8 | 1.6 | 5.1 | 562 | 169 | 20.3 |
| WNS10-1.25-Q | 193 | 105 | 218.63 | 10 | 1.25 | 5.8 | 694 | 157 | 21.9 |
| WNS10-1.6-Q | 204 | 105 | 218.63 | 10 | 1.6 | 5.8 | 712 | 168 | 21.9 |
| WNS15-1.25-Q | 193 | 105 | 285.9 | 15 | 1.25 | 11.6 | 1050 | 170 | 35 |
| WNS15-1.6-Q | 204 | 105 | 285.9 | 15 | 1.6 | 11.6 | 1057 | 166 | 35 |
| WNS20-1.25-Q | 193 | 105 | 440 | 20 | 1.25 | 16 | 1391 | 164 | 43.2 |
| WNS20-1.6-Q | 204 | 105 | 440 | 20 | 1.6 | 16 | 1401 | 165 | 43.2 |
Note: The description might be incorrect, please contact us for confirmation.
