B0.63-1.0 Marine Low Pressure Air Receiver Tank | DNV/ABS Certified | 0.63m³ Capacity
Product Overview
The B0.63-1.0 Marine Low Pressure Air Receiver Tank is a certified marine-grade compressed air storage vessel specifically engineered for maritime low-pressure applications. With 0.63m³ capacity and 1.0 MPa working pressure, it delivers reliable performance for engine starting, pneumatic controls, and onboard tool operations. Manufactured from corrosion-resistant carbon steel with class-approved construction, it ensures exceptional durability in harsh marine environments.
Key Features & Benefits
-
Marine Classification Certified: Complies with DNV, ABS, BV, CCS, and other major marine society standards
-
Saltwater Environment Optimized: Features anti-corrosion coatings and marine-grade materials to withstand oceanic conditions
-
Drinking Water System Compatible: Equipped with food-grade natural rubber diaphragm for potable air applications
-
Maintenance-Free Operation: Hermetic sealing system prevents contamination and requires zero routine maintenance
-
Extended Service Life: Reinforced diaphragm rated for 200,000+ operational cycles under marine conditions
-
Compact & Space-Efficient: Optimized dimensions (1800×790×1400mm) for easy installation in confined engine room spaces
-
Complete Safety Package: Includes pressure gauges, safety valves, and drainage systems for reliable operation
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | B0.63-1.0 |
| Capacity | 0.63 m³ |
| Design Pressure | 1.1 MPa |
| Working Pressure | 1.0 MPa |
| Design Temperature | 100°C |
| Internal Diameter | 790 mm |
| Length | 1800 mm |
| Height | 1400 mm |
| Weight | 487 kg |
| Material Standard | Marine carbon steel |
Marine Applications
-
Main and auxiliary diesel engine starting systems
-
Control air for marine automation and valve operations
-
Deck machinery and pneumatic tool power supply
-
Potable water system air storage and distribution
-
Emergency backup air supply circuits
-
Offshore platform pneumatic equipment
Compliance & Certification
Manufactured according to marine specifications and available with certification from DNV, ABS, BV, CCS, RINA, and other classification societies.
The description/sizes may be different with goods, please check with us when order.
