Marine Horizontal Boiler

Marine Horizontal Hot Water Boiler – Efficient & Reliable Heating Solution for Marine Applications

Product Overview
The Marine Horizontal Hot Water Boiler is a high-performance heating system designed for marine environments. Its horizontal structure and optimized flue gas flow ensure efficient heat transfer, providing a stable supply of hot water for various onboard applications. Engineered to operate under demanding conditions, this boiler is ideal for commercial vessels, offshore platforms, and industrial marine systems.

Key Features

✅ Horizontal Design for Compact Installation
✅ Single-Phase Hot Water Operation – No Evaporation or Steam Generation
✅ High-Temperature Resistance and Corrosion Protection
✅ Suitable for Marine Environments – Saltwater and Humidity Resistant
✅ Low Maintenance and Easy Operation
✅ Customizable Models for Various Marine Heating Needs

Technical Specifications

Model	Heat Production (kg/h)	Working Pressure (MPa)	Outline Dimensions (mm)	Weight (kg)
LYK 166-0.3	166	0.3	1450×φ500×850	450
LYK250/3-80-2	250	0.2	2190×φ580×900	770
LYK294-0.4	294	0.4	1910×φ746×962	935
LYK375/4.8-90-1	375	0.5	1835×φ666×930	840
LYK418-0.4	418	0.4	1900×φ690×950	920
LYK523-0.4	523	0.4	2002×φ760×980	944
LYK750-0.4	750	0.4	2100×φ910×1250	1236
LYK840-0.4	840	0.4	2100×φ960×1200	1580
LYK 1000-0.4	1000	0.4	2200×φ1100×1300	1560
LYK 1250-0.4	1250	0.4	2250×φ1200×1350	1840
LYK 1670-0.4	1670	0.4	2400×φ1376×1420	2490
LYK2880-0.4	2880	0.4	3175×φ1316×1560	3536
LYK5000-0.4	5000	0.4	3860×φ1596×1688	4335
