MARINE GRAVITY LUFFING ARM TYPE DAVIT
PRODUCT DESCRIPTION
Totally enclosed lifeboat with gravity luffing arm type davit are used on tanker, dry cargo vessel, container vessel etc, the lifeboats are used to protect and provide the escape in an emergency evacuation or accident happen on board or offshore platform.
PRODUCT SPECIFICATION TABLE
| TOTALLY ENCLOSED LIFEBOAT MODEL | GRAVITY LUFFING ARM TYPE DAVIT MODEL | MAX. DAVIT LOAD (KN) | DIMENSIONS (MM) – B (Breadth) | DIMENSIONS (MM) – H (Height) | WINCH LOAD (KN) |
|---|---|---|---|---|---|
| NML50C | NMD45KN | 45 | 2540 | 4765 | 42 |
| NM50C/F | NMD55KN | 55 | 3066 | 5381 | 42 |
| NM57C/F, NM65C/F | NMD60KN | 60 | 3125 | 5602 | 50/63 |
| NM58C/F | NMD65KN | 65 | 3535 | 6202 | 50 |
| NM75C/F | NMD85KN | 85 | 3465 | 6700 | 63 |
| NM85C/F | NMD120KN | 120 | 4120 | 7500 | 80 |
| NM103C/F | NMD180KN | 180 | 4560 | 8385 | 125 |
Note: The description may be different with the product, please contact us for quotation.
