Marine Fixed Boom Cranes
A 5kN marine fixed boom cranes are a compact yet powerful lifting solution designed for precise load handling in marine environments. With a maximum capacity of 5 kilonewtons (≈509 kg), this crane is ideal for:
-
Deck operations on ships and offshore platforms
-
Equipment handling in ports and shipyards
-
Cargo transfer for small to medium loads
Key Features:
-
Fixed boom design for stability in rough seas
-
Electric-powered operation with energy efficiency
-
Remote/local control options for flexible use
Material Options
-
Carbon Steel: Heavy-duty strength for demanding conditions
-
Stainless Steel: Superior corrosion resistance
-
Aluminum: Lightweight yet durable alternative
Advantages & Features
-
Electric Drive System: Smooth, low-maintenance operation
-
Wide Capacity Range: Models available from 0.5kN to 300kN
-
Maintenance-Friendly: Easy access for lubrication and inspections
-
Robust Construction: High-strength build with efficient gearbox
-
Custom Solutions: Tailored designs for specific operational needs
-
Motor Options: Standard or explosion-proof configurations
-
Dual Safety System: Automatic & manual overload protection
-
Certified Quality: Compliant with BV, LR, RINA standards
Optional Upgrades:
-
360° rotation capability
-
Anti-corrosion coatings for harsh environments
-
Advanced control systems (anti-sway, precision positioning)
| Specifications | |
| SWL | 5KN |
| Working Radius | 2.5m |
| Power source | 440v/60Hz |
| Protect Class | IP56 |
| Insulate Class | F |
| Working Type | S1 |
| Hoisting Speed | ≥9m/min |
| Hoisting Height | 50m |
| Slewing Speed | ≥1r/min |
| Slewing Angle | 360° |
| Tirm | ≤2° |
| Heel | ≤5° |
| Motor Power | 1.5KW |
| Motor Speed | 1760r/min |
