Marine Electric Slewing Crane
Application
A marine electric slewing crane is a versatile lifting solution powered by an electric motor, capable of rotating 360° around its central axis for precise load positioning. These cranes are widely used in construction, manufacturing, and industrial operations requiring heavy load handling. Mounted on a sturdy pedestal base, they support various attachments (hooks, grabs, buckets) for diverse material handling needs.
Key Features:
-
Electric-powered operation (mains-powered) with remote or onboard control options
-
Advanced safety systems: Anti-collision technology and overload protection
-
Precision rotation: Smooth slewing movement for accurate load placement
-
Adaptable configurations: Customizable for specific industrial requirements
Material Options
-
Aluminum (lightweight corrosion resistance)
-
Stainless steel (marine-grade durability)
-
Carbon steel (heavy-duty structural strength)
Advantages and Features
-
Superior corrosion resistance for extended service life
-
Broad capacity range: 0.5KN to 300KN working load
-
Maintenance-optimized design with accessible lubrication points
-
Robust construction with high-performance gearbox
-
Custom engineering available for specialized applications
-
Dual motor options: Standard or explosion-proof models
-
Redundant safety: Combined automatic/manual overload systems
-
Full-circle operation: Unlimited 360° rotation (with programmable limits)
-
Certified compliance: CCS, BV, LR and other international standards
Parameters:
| Safety Load | Hoisting Speed | Luffing Time | Slewing Speed | Working Radius | Elc. Motor Power | |
| KN | m/min | s | rpm | Max. | Min. | KW |
| 5 | 12 | 35 | 0.8 | 8 | 2 | 2.2/1.5/1.5 |
| 10 | 10 | 35 | 0.7 | 8 | 2 | 3.7/2.2/1.5 |
| 15 | 12 | 40 | 0.7 | 8 | 2 | 5.5/3.7/2.2 |
| 20 | 10 | 50 | 0.6 | 10 | 2.5 | 7.5/5.5/3.7 |
| 30 | 10 | 60 | 0.55 | 10 | 3 | 11/7.5/5.5 |
| 40 | 10 | 65 | 0.5 | 12 | 3 | 15/11/7.5 |
| 50 | 10 | 85 | 0.4 | 15 | 4 | 18.5/11/11 |
The description/sizes may be different with goods, please check with us when order.
