Marine Electric Anchor Windlass
Application
The Marine Electric Anchor Windlass is an essential anchoring system for vessels, providing reliable anchor handling through electric power. Designed for smooth operation and heavy-duty performance, it is ideal for:
-
Commercial ships (cargo, tankers, offshore vessels)
-
Yachts & large boats
-
Military & patrol vessels
Key Features:
✔ Electric Motor Drive – Consistent power for smooth anchor retrieval
✔ Remote & Local Control – Operated from the bridge or directly at the windlass
✔ High Load Capacity – Handles heavy anchor chains (up to Ø120mm)
✔ Multiple Configurations – Single/double gypsy, with/without warping drum
Safety & Compliance:
-
Backup Systems Recommended (emergency power options available)
-
Class-Certified – Meets BV, LR, RINA, and other marine standards
-
Regular Maintenance Required – Ensures long-term reliability
[View detailed specifications here]
Material Options
| Material | Benefits | Best For |
|---|---|---|
| Cast Steel | High strength, cost-effective | General marine applications |
| 316L Stainless Steel | Superior corrosion resistance | Harsh saltwater environments |
Advantages & Features
-
Robust Construction – Heavy-duty gearbox and frame
-
Dual Control Modes – Bridge remote + local manual operation
-
Easy Maintenance – Accessible lubrication points & inspection ports
-
Marine-Grade Durability – Resists corrosion & extreme weather
-
Customizable Options:
-
Warping head (for rope handling)
-
Drum attachment (additional line handling)
-
-
Safety & Convenience:
-
Automatic brake system (prevents accidental release)
-
Smooth chain engagement (reduces wear)
-
-
Custom Engineering – Tailored to vessel size & anchor weight
-
Brake & Clutch Options:
-
Manual (mechanical locking)
-
Hydraulic (smoother engagement)
-
-
Certified Quality – Approved by BV, LR, RINA, DNV, ABS
Parameters:
| Chain Dia.(mm) | Working Speed(m/min) | Mooring Load(kN) | Working Load(kN) | Supporting Load(kN) | Motor Power(kW) |
| 12.5 | ≥9 | 5 | 5.9 | 30 | 3/1.2 |
| 14/16/17.5 | ≥9 | 8 | 8.3/10.9/13.0 | 51/67/80 | 4.3/1.7 |
| 19/20.5/22 | ≥9 | 10 | 15.3/17.9/20.6 | 95/110/126 | 8.5/3.5 |
| 24/26 | ≥9 | 20 | 24.5/28.7 | 149/175 | 8.5/3.5 |
| 28/30 | ≥9 | 30 | 33.3/38.3 | 202/231 | 11/11/7.5 |
| 32/34/36 | ≥9 | 30 | 43.5/49.1/55.1 | 261/294/329 | 16/16/11 |
| 38/40/42 | ≥9 | 40 | 61.4/68.0/75.0 | 365/402/442 | 22/22/16 |
| 44/46/48 | ≥9 | 50 | 82.3/89.9/97.9 | 483/526/570 | 30/30/22 |
| 50/52/54 | ≥9 | 50 | 106.3/114.9/123.9 | 617/664/713 | 30/30/22 |
| 56/58/60 | ≥9 | 60 | 133.3/143.0/153 | 764/816/870 | 45/45/30 |
| 62/64 | ≥9 | 80 | 163.4/174.1 | 925/982 | 45/45/30 |
| 66/68 | ≥9 | 100 | 185.1/196.5 | 1040/1098 | 45/45/30 |
| 70/73 | ≥9 | 100 | 208.3/226.5 | 1160/1254 | 60/60/45 |
| 76/78 | ≥9 | 125 | 245.5/258.6 | 1350/1416 | 60/60/45 |
| 81/84 | ≥9 | 140 | 311.7/335.2 | 2171/2320 | 75/75/36 |
| 87/90 | ≥9 | 150 | 359.5/384.8 | 2473/2629 | 75/75/36 |
| 92/95 | ≥9 | 200 | 402.0/428.7 | 2735/2898 | 85/85/64 |
| 97/100 | ≥9 | 250 | 446.9/475.0 | 2995/3162 | 100/100/50 |
| 05/107 | ≥9 | 300 | 523.7/543.8 | 3612/3750 | 110/110/55 |
| 112/114 | ≥9 | 350 | 595.8/617.3 | 4109/4228 | 132/132/66 |
The description/sizes may be different with goods, please check with us when order.
