Marine double eccentric worm wheel type manual butterfly valve

Marine double eccentric worm wheel type manual butterfly valve

Place of Origin: Made In China
Delivery Time: 15-30 days
Click here to send inquiry via whatsapp

Category:

Marine double eccentric worm wheel type manual butterfly valve

Dimensions

Nominal pressure (MPa) Nominal diameter (mm) Structure & flange dimension (ISO, JIS, DIN) ISO (GB2501-89) JIS DIN ISO JIS DIN
H L D L D L D n d n d n d
80 350 140 160 64 200 160 58 180 145 49 200 160 8 4-18 4 4-19 8 4-18
100 380 154 160 64 220 160 64.5 200 165 56 220 180 8 4-18 8 4-19 8 4-18
125 438 174 160 70 250 210 69.5 235 200 64 250 210 8 4-18 8 4-19 8 4-18
150 482 196 180 70 265 240 90 265 230 70 285 240 8 4-22 8 4-19 8 4-22
200 562 226 180 85 340 295 100 320 280 71 340 295 8 4-22 8 4-23 8 4-22
250 648 269 210 95 395 350 110 385 345 76 395 350 12 4-22 12 4-23 12 4-22
300 730 300 210 100 445 400 110 430 390 83 445 400 12 4-22 12 4-23 12 4-22
350 782 326 275 120 505 460 120 480 435 92 505 460 16 4-22 16 4-25 16 4-25
400 850 350 275 140 562 515 130 540 495 102 565 515 16 4-25 16 4-25 16 4-26
450 945 395 275 160 622 615 155 600 555 114 615 565 20 4-26 20 4-25 20 4-26
500 1010 405 275 180 632 670 180 650 605 127 670 620 20 4-26 20 4-25 20 4-26
600 1195 500 420 200 682 780 200 700 710 155 780 725 20 4-30 20 4-27 20 4-30
650 1245 500 420 200 692 835 200 710 825 170 685 835 780 24 4-30 24 4-27 24 4-30
80 350 140 160 64 200 160 58 185 150 49 200 160 8 4-18 8 4-19 8 4-18
100 380 154 160 64 220 160 64.5 210 175 56 220 180 8 4-18 8 4-19 8 4-18
125 438 174 160 70 250 210 69.5 250 210 64 250 210 8 4-18 8 4-19 8 4-18
150 482 196 180 70 265 240 90 265 230 70 285 240 8 4-22 8 4-23 8 4-22
200 562 226 180 85 340 295 100 320 280 71 340 295 12 4-22 12 4-23 12 4-22
250 648 269 210 95 395 350 110 385 345 76 395 350 12 4-22 12 4-23 12 4-22
300 730 300 210 100 445 400 110 430 390 83 445 400 12 4-22 12 4-23 12 4-22
350 782 326 275 120 505 460 120 480 435 92 505 460 16 4-22 16 4-25 16 4-25
400 850 350 275 140 562 515 130 540 495 102 565 515 16 4-25 16 4-25 16 4-26
450 945 395 275 160 622 615 155 600 555 114 615 565 20 4-26 20 4-25 20 4-26
500 1010 405 275 180 632 670 180 650 605 127 670 620 20 4-26 20 4-25 20 4-26
600 1195 500 420 200 682 780 200 700 710 155 780 725 20 4-30 20 4-27 20 4-30
650 1245 500 420 200 692 835 200 710 825 170 685 835 780 24 4-30 24 4-27 24 4-30
80 350 140 160 64 200 160 58 185 150 49 200 160 8 4-18 8 4-19 8 4-18
100 380 154 160 64 220 160 64.5 210 175 56 220 180 8 4-18 8 4-19 8 4-18
125 438 174 160 70 250 210 69.5 250 210 64 250 210 8 4-18 8 4-19 8 4-18
150 482 196 180 70 265 240 90 265 230 70 285 240 8 4-22 8 4-23 8 4-22
200 562 226 180 85 340 295 100 320 280 71 340 295 12 4-22 12 4-23 12 4-22
250 648 269 210 95 395 350 110 385 345 76 395 350 12 4-22 12 4-23 12 4-22
300 730 300 210 100 445 400 110 430 390 83 445 400 12 4-22 12 4-23 12 4-22
350 782 326 275 120 505 460 120 480 435 92 505 460 16 4-22 16 4-25 16 4-25
400 850 350 275 140 562 515 130 540 495 102 565 515 16 4-25 16 4-25 16 4-26

Note: The description may be different with the product, please contact us for quotation.
