Marine Deck Hatch Covers – Watertight & Weatherproof Solutions for Ships
Premium Marine Deck Hatch Covers for Enhanced Ship Safety
Marine deck hatch covers are critical components installed on ship main decks, designed to prevent water ingress from waves and rainwater. Available in aluminum and steel constructions, our marine-grade hatches ensure superior protection while meeting IACS certification standards for maritime safety.
Key Features of Our Marine Deck Hatches:
-
Watertight & Weatherproof: Engineered to keep cabins dry in harsh marine conditions.
-
High-Strength Materials: Available in aluminum and steel for durability and corrosion resistance.
-
IACS Certified: Compliant with international maritime safety regulations.
-
Multiple Size Options: Customizable dimensions to fit various vessel requirements.
-
Secure Fastening: Equipped with M16/M20 butterfly clips for reliable sealing.
Marine Deck Hatch Specifications
| Type | Nominal Size (L×B) | Clear Size (L1×B1×R1) | Cover Size (L2×B2) | Thickness (t) | Hatch Height (H) | Clip Dia. | Clip Qty | Weight (Kg) |
|---|---|---|---|---|---|---|---|---|
| A AL AS | 450×630 | 420×600×100 | 508×688 | 4, 6, 8 | 100-600 | M16 | 4 | 24.4 – 37.7 |
| A AL AS | 530×530 | 500×500×100 | 588×588 | 4, 6, 8 | 100-600 | M16 | 4 | 24.2 – 37.4 |
| A AL AS | 630×630 | 600×600×100 | 682×688 | 4, 6, 8 | 100-600 | M20 | 4 | 31 – 48.5 |
| A AL AS | 630×830 | 600×800×100 | 688×888 | 4, 6, 8 | 100-600 | M20 | 4 | 37.4 – 59.7 |
| A AL AS | 830×830 | 800×800×100 | 888×888 | 4, 6, 8 | 100-600 | M20 | 6 | 47.1 – 75.3 |
| A AL AS | 830×1230 | 800×1200×100 | 888×1288 | 4, 6, 8 | 100-600 | M20 | 8 | 65.2 – 175.2 |
| A AL AS | 1030×1030 | 1000×1000×100 | 1092×1092 | 4, 6, 8 | 100-600 | M20 | 8 | 146.6 – 190.9 |
| A AL AS | 1330×1330 | 1300×1300×100 | 1396×1396 | 8 | 100-600 | M20 | 8 | 331.3 |
The description/sizes may be different with goods, please check with us when order.
