Marine Black Water Treatment Plant
Our marine black water treatment plant is an essential pollution prevention device for ships, effectively processing fecal sewage from lavatories and grey water from galleys, laundries, and baths. This high-capacity system meets the strictest international marine effluent standards while operating reliably in harsh ocean environments.
Key Features & Benefits
✔ Dual Waste Stream Processing – Handles both black water and grey water
✔ High-Efficiency Treatment – Processes 42 m³/day average load (46.2 m³/day peak)
✔ Compact Marine Design – Space-optimized for easy vessel installation
✔ Automatic Operation – Minimal supervision required
✔ Global Certifications Available – ABS, BV, DNV, LR, and other IACS options
Technical Specifications
| Parameter | Specification |
|---|---|
| Hydraulic Capacity | 12.6-46.2 m³/day |
| Organic Loading | 21 kg BOD5/day |
| System Pressure Rating | 0.25 MPa |
| Discharge Standards | Exceeds IMO MEPC.227(64) requirements |
Certified Effluent Quality
Our system delivers consistent performance that meets:
✅ BOD5 ≤25 mg/L
✅ COD ≤125 mg/L
✅ TSS ≤35 mg/L
✅ Coliform ≤100 CFU/100mL
✅ Nutrient Removal (70% nitrogen, 80% phosphorus)
✅ pH 6.0-8.5 (chlorine-free operation)
Note: The description might be incorrect, please contact us for confirmation.
