BOS – 1200 Marine Ballast Water Treatment Plant for Modern Vessels
The BOS – 1200 Marine Ballast Water Treatment Plant stands as a high – capacity, fully physical ballast water treatment solution tailored for contemporary commercial vessels that demand dependable and environmentally – conscious ballast water management. By integrating an advanced filtration and ultraviolet disinfection technology, this system effectively processes ballast water to strictly adhere to IMO D – 2 and USCG standards, all without relying on any chemicals. With a remarkable treatment capacity of up to 1200 m³/h, the BOS – 1200 offers straightforward installation, simple operation, and unmatched reliability for ships of varying sizes, making it an ideal choice for global shipping operations.
Marine Ballast Water Treatment Plant Key Features & Advantages
✅ High – Volume Treatment Capability: Capable of handling a flow rate ranging from 150 to 1300 m³/h, making it well – suited for large – scale commercial and cargo vessels that require efficient ballast water management.
✅ Purely Physical Treatment Method: The combination of filtration and UV technology ensures an eco – friendly and chemical – free operation, safeguarding the marine environment from potential chemical pollution.
✅ Compliance with International Regulations: Fully meets all international ballast water discharge standards set by the USCG and IMO, enabling vessels to operate smoothly in different regions without regulatory concerns.
✅ Advanced UV Disinfection Performance: Medium – pressure UV lamps are employed to effectively inactivate a wide range of organisms and pathogens present in the ballast water, ensuring high – quality treatment.
✅ Automatic Self – Cleaning Filter Mechanism: Utilizes negative pressure suction to remove particles larger than 50μm without the need for manual intervention, reducing maintenance requirements and ensuring continuous operation.
✅ Flexible Installation and Operation: Available in both horizontal and vertical configurations, allowing it to fit into diverse engine room layouts for easy integration and operation.
Advanced Treatment Technology
Mechanical Filtration Stage
- Self – Cleaning Filter Unit: This unit automatically eliminates organisms and solids larger than 50µm from the ballast water, preventing them from entering the subsequent treatment stages and ensuring the purity of the treated water.
- Multiple Control Modes: It offers three control modes – time – based, pressure – differential, and manual operation. This flexibility allows operators to choose the most suitable mode based on the specific operating conditions of the vessel.
- Low – Maintenance Design: The automatic backflush feature ensures continuous operation without the risk of clogging. It regularly cleans the filter, maintaining its optimal performance and reducing the need for frequent manual maintenance.
Ultraviolet Disinfection Stage
- Medium – Pressure UV Technology: Effectively inactivates aquatic nuisance species (ANS) and pathogens in the ballast water. The medium – pressure UV lamps emit a broad – spectrum of ultraviolet light, which disrupts the DNA and RNA of these organisms, rendering them harmless.
- Omnidirectional Anti – Scaling: The ultrasonic cleaning system prevents the formation of biofilm and scaling on the quartz sleeves of the UV lamps. This ensures that the UV light can penetrate the water effectively, maintaining high – efficiency disinfection.
- High – Efficiency Disinfection Guarantee: The system is designed to achieve an organism inactivation rate of ≥99.9%, providing a high level of protection against the spread of invasive species through ballast water discharge.
Technical Specifications
Filter Unit (Model: FH1250)
- Treatment Capacity: Ranges from 150 to 1300 m³/h, enabling it to handle the ballast water requirements of different – sized vessels.
- Dimensions (W×D×H): Measures 2687 × 816 × 1265 mm, providing a compact yet efficient filtration solution for engine rooms.
- Inlet/Outlet Diameter: Features a DN400 diameter, facilitating the smooth flow of ballast water in and out of the filter unit.
- Configuration Options: Can be installed either horizontally or vertically, allowing for flexible placement according to the available space in the engine room.
UV Unit (Model: UV1200)
- Treatment Capacity: Matches that of the filter unit, with a range of 150 to 1300 m³/h, ensuring consistent and effective disinfection of the ballast water.
- Dimensions (W×D×H): Has dimensions of 1350 × 1005 × 600 mm, making it a relatively compact unit that can be easily integrated into the overall ballast water treatment system.
- Inlet/Outlet Diameter: The inlet and outlet diameter is 400 mm, ensuring a seamless connection with the filter unit and the rest of the ballast water pipeline.
- Weight: Weighs 566 kg, providing a stable and robust structure for reliable operation.
- Cleaning System: Incorporates ultrasonic anti – scaling technology to maintain the performance of the UV lamps and ensure high – efficiency disinfection.
System Components
Filter Unit
- Negative Pressure Self – Cleaning Filter: Removes large particles and organisms larger than 50µm from the ballast water, preventing blockages and ensuring the smooth operation of the subsequent treatment stages.
- Automatic Backflush Function: Can be triggered by time, pressure, or manual control. This automatic cleaning mechanism reduces the need for manual intervention and keeps the filter in optimal condition.
UV Disinfection Unit
- Medium – Pressure Ultraviolet Lamps: Emit powerful ultraviolet light to inactivate organisms and pathogens in the ballast water, providing effective disinfection.
- Ultrasonic Automatic Cleaning System: Prevents the build – up of biofilm and scaling on the quartz sleeves of the UV lamps, ensuring consistent and high – efficiency disinfection.
- Real – Time Monitoring: Monitors the UV intensity and temperature in real – time, allowing operators to quickly identify any potential issues and take appropriate actions to maintain the system’s performance.
Control Unit
- One – Touch Automatic Operation: Simplifies the operation of the entire ballast water treatment system, enabling operators to start and stop the system with a single touch.
- Continuous System Monitoring and Data Logging: Continuously monitors the performance of the system and logs relevant data, such as treatment capacity, UV intensity, and temperature. This data can be used for performance analysis and regulatory compliance reporting.
- User – Friendly Interface with Fault Alarm System: Features a user – friendly interface that is easy to navigate. In case of any faults or abnormalities in the system, an alarm is triggered immediately, alerting the operators to take prompt action.
Certifications & Approvals
The BOS – 1200 BWMS has obtained certifications from leading classification societies across the globe, including USCG, BV, CCS, NK, DNV, ABS, LR, RINA, RS, and GL. These certifications validate the system’s compliance with international standards and its reliability in ballast water treatment, providing ship owners and operators with confidence in its performance.
