Marine Angle Check Valve – JIS F7400 Certified, Customizable Materials & OEM Support
Product Overview
Our marine angle check valve is engineered to meet rigorous JIS F7400 standards, ensuring superior performance and reliability in marine and offshore applications. Designed for seawater, fuel, and compressed air systems, this angle-type non-return valve prevents backflow and protects essential onboard machinery. We offer full customization of valve materials—including bronze, brass, and more—tailored to your specific operational requirements.
Key Features & Benefits
-
JIS F7400 Compliant Design: Manufactured in accordance with international marine valve standards for guaranteed safety and compatibility.
-
Wide Material Selection: Choose between bronze, brass, and other alloys for optimal corrosion resistance, mechanical performance, and cost efficiency.
-
OEM & ODM Services: We support custom valve designs, labels, and packaging to meet unique project specifications.
-
Decade of Export Expertise: With nearly 10 years of experience in global marine valve supply, we understand the demands of international clients.
-
Sample and Small Orders Welcome: Ideal for prototyping, testing, and low-volume procurement.
-
24/7 Customer Support: Get professional replies and technical assistance within 24 hours.
Configuration & Material Options
| Part Name | Material | Advantages/Applications |
|---|---|---|
| Valve Body | Bronze | Excellent castability, low friction, high mechanical strength, ideal for seawater environments. |
| Brass | Cost-effective with decent machinability; suitable for low-pressure systems but less corrosion-resistant. | |
| Valve Bonnet | Bronze | Superior corrosion and wear resistance, stable in chemical and marine conditions. |
| Brass | High strength and antifriction properties; resistant to atmospheric and seawater corrosion, but may be prone to stress cracking. | |
| Valve Disc | Bronze | Outstanding low-temperature and seawater resistance, ideal for subzero and saltwater applications. |
| Brass | Good hot and cold workability, machinability, and weldability; economical but susceptible to corrosion in certain environments. | |
| Gasket | Non-Asbestos | Provides exceptional sealing performance (air, water, fuel), high temperature and pressure resistance, and enhanced oil resistance. |
The description/sizes may be different with goods, please check with us when order.
