Marine Inflatable Life Raft SOLAS Approved (6-Person Capacity)
Emergency Throw-Overboard Life Raft System
A critical SOLAS-compliant safety device designed for rapid deployment during maritime emergencies. Features automatic inflation upon water contact or via hydrostatic release mechanism for fail-safe operation.
Key Specifications
Capacity Options
Available in multiple sizes: 6, 10, 15, 20, or 25 persons
Safety Features
✔ Auto-Inflation System
-
Deploys within seconds when thrown overboard
-
Hydrostatic Release Unit (HRU) activates if vessel sinks rapidly (self-releasing at 1.5-4m depth)
✔ Protective Canopy
-
Weatherproof cover shields survivors from exposure
-
Thermal insulation blocks cold seawater transfer
✔ Redundant Buoyancy
-
Twin independent buoyancy tubes for enhanced safety
Certifications
-
Fully complies with:
-
SOLAS 1974 (1996 Amendments)
-
LSA Code (MSC.48(66), MSC.218(82))
-
MSC.81(70) & MSC.226(82) Testing Standards
-
-
Approved by CCS & CE
Technical Parameters
-
Type: Throw-overboard (manual deployment)
-
Max Storage Height: 18-30 meters
-
Floor: Watertight insulated design
Parameters:
| Type | Width(mm) | Height(mm) | Rated Person | Physical Forms | Length(mm) | Container Dia(mm) | Container Length(mm) | Weight(kg) |
| A6 | 2160 | 1350 | 6P | Regular Octagon | 2160 | 620 | 1100 | 85 |
| A10 | 2730 | 1450 | 10P | Regular Octagon | 2730 | 680 | 1150 | 120 |
| A15 | 3405 | 1500 | 15P | Regular Twelev-side | 3405 | 700 | 1300 | 140 |
| A16 | 3405 | 1500 | 16P | Regular Twelev-side | 3405 | 700 | 1300 | 140 |
| A20 | 3080 | 1650 | 20P | Long Eight-side | 4280 | 730 | 1495 | 175 |
| A25 | 3450 | 1800 | 25P | Long Eight-side | 4700 | 730 | 1495 | 195 |
