Kevel Chock – The Versatile Mooring Solution for Modern Vessels
Premium Cast Steel Construction for Maximum Durability
Our Kevel chock is expertly crafted from high-grade cast steel to withstand the toughest marine environments. Designed to serve multiple mooring functions, this essential deck fitting provides reliable performance voyage after voyage.
Available in Industry-Standard Sizes
Choose from our range of proven dimensions to meet your vessel’s requirements:
-
24″
-
30″
-
36″
-
42″
-
48″
Parameters:
| Dimension(inch) | ||||||||||||||
| A | B | D | C | E | F | G | K | H | M | N | O | R | ||
| 24” | 3 | 17 | 2004/1/2 | 6 | 2001/1/2 | 2005/1/2 | 2001/1/2 | 11 | 8 | 2 | 2001/1/2 | 1 | ||
| 30” | 4 | 2020/1/4 | 2005/5/8 | 7 | 2002/3/8 | 2006/7/8 | 2003/1/4 | 14 | 2009/1/2 | 2 | 2002/3/8 | 1-/-8 | ||
| 36” | 5 | 2023/1/2 | 2006/3/4 | 8 | 2003/1/4 | 2008/1/4 | 4 | 17 | 11 | 2002/1/2 | 2003/1/4 | 2001/3/4 | ||
| 42” | 6 | 2026/3/4 | 2007/7/8 | 9 | 2004/1/8 | 2009/5/8 | 2004/3/4 | 20 | 2002/1/2 | 2002/3/4 | 2004/1/8 | 2002/1/8 | ||
| 48” | 7 | 30 | 9 | 10 | 10 | 11 | 2005/1/2 | 23 | 14 | 4 | 5 | 2002/1/2 | ||
The description/sizes may be different with goods, please check with us when order.
