JIS F7364 Marine-Grade Heavy-Duty Cast Iron Gate Valve
Overview
Our JIS F7364 Marine-Grade Heavy-Duty Cast Iron Gate Valve is a premium-quality rising stem gate valve specifically crafted for dependable isolation and precise flow control in marine fuel oil and lubricating systems. Constructed in strict accordance with the Japanese Industrial Standard F7364, this 10K pressure-rated gate valve boasts a robust cast iron body paired with a bronze disc and seat, ensuring a bubble-tight shutoff even in the most challenging marine environments. It adheres to JIS B2220 steel pipe flange dimensions, facilitating seamless integration into ship piping networks for both new construction and retrofit maintenance projects.
Key Features & Advantages
- Compliance with JIS F7364 Standard: Precision-engineered to meet the stringent requirements of Japanese Industrial Standard specifications.
- 10K Pressure Rating: Ideal for medium-pressure applications, with a pressure capacity of 100 psi.
- Bronze Disc and Seat: Delivers exceptional sealing performance and outstanding resistance to corrosion.
- Durable Cast Iron Construction: Features a robust body material with superior mechanical properties for long-lasting performance.
- Rising Stem Design: Provides clear visual indication of valve position for effortless operation status monitoring.
- Bidirectional Sealing Capability: Ensures reliable shut-off in both directions of fluid flow.
- JIS B2220 Flange Compatibility: Standard flange dimensions guarantee straightforward installation and compatibility.
- Full Bore Design: Minimizes pressure drop when the valve is fully open, optimizing flow efficiency.
Technical Specifications
- Design Standard: JIS F7364
- Flange Standard: JIS B2220
- Pressure Rating: 10K (100 psi)
- Temperature Range: From -20°C to 200°C
- Body Material: Cast Iron (equivalent to FC200/GG25)
- Disc and Seat Material: Bronze
- Stem Material: Brass
- Nominal Diameter Range: DN50 to DN600 (2″ to 24″)
- Operation Method: Manual Handwheel with Rising Stem
- Suitable Media: Fuel Oil, Lubricating Oil, Seawater, Utility Fluids
Dimension Table (JIS F7364 10K Standard)
| IMPA Code | Model | L (mm) | D (mm) | C (mm) | Bolt Holes | h (mm) | t (mm) | H (mm) | D2 (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 750821 | 7364 10K050 | 200 | 155 | 120 | 4 | 19 | 20 | 300 | 140 |
| 750822 | 7364 10K065 | 220 | 175 | 140 | 4 | 19 | 22 | 350 | 160 |
| 750823 | 7364 10K080 | 230 | 185 | 150 | 8 | 19 | 22 | 400 | 180 |
| 750824 | 7364 10K100 | 250 | 210 | 175 | 8 | 19 | 24 | 450 | 200 |
| 750825 | 7364 10K125 | 270 | 250 | 210 | 8 | 23 | 24 | 520 | 224 |
| 750826 | 7364 10K150 | 290 | 280 | 240 | 8 | 23 | 26 | 580 | 250 |
| 750827 | 7364 10K200 | 320 | 330 | 290 | 12 | 23 | 26 | 700 | 315 |
| 750828 | 7364 10K250 | 380 | 400 | 355 | 12 | 25 | 30 | 840 | 400 |
| 750829 | 7364 10K300 | 440 | 445 | 400 | 16 | 25 | 32 | 960 | 450 |
| 750830 | 7364 10K350 | 500 | 490 | 445 | 16 | 25 | 34 | 1050 | 500 |
| 750831 | 7364 10K400 | 590 | 560 | 510 | 16 | 27 | 36 | 1150 | 560 |
| 750832 | 7364 10K450 | 640 | 620 | 565 | 20 | 27 | 38 | 1260 | 600 |
| 750833 | 7364 10K500 | 710 | 675 | 620 | 20 | 27 | 40 | 1380 | 680 |
| 750834 | 7364 10K550 | 780 | 745 | 680 | 20 | 33 | – | – | – |
| 750835 | 7364 10K600 | 850 | 795 | 730 | 24 | 33 | – | – | – |
The description/sizes may be different with goods, please check with us when order.
