Marine Bronze Gate Valve | JIS F7363 5K Certified for Water Treatment & Distribution Systems
Product Overview
Our JIS F7363 marine bronze gate valve is specifically engineered for water treatment applications, water distribution systems, and industrial pressure management in marine environments. Featuring all-bronze construction for superior corrosion resistance, this valve ensures reliable performance in freshwater, seawater, and industrial fluid handling applications. With a decade of export experience, we deliver quality valves that meet the highest international standards.
Key Features & Benefits
-
JIS F7363 Compliance: Manufactured to Japanese Industrial Standards for marine valves
-
Full Bronze Construction: Excellent corrosion resistance for water and industrial applications
-
5K Pressure Rating: Ideal for low to medium pressure water systems
-
Gate Valve Design: Provides straight-through flow with minimal pressure drop
-
Decade of Expertise: 10 years of specialized marine valve manufacturing and export experience
-
Excellent Quality Control: Rigorous inspection throughout manufacturing process
-
Complete Product Range: Various styles and comprehensive series available
Technical Specifications
-
Standard: JIS F7363
-
Nominal Diameter: DN50 to DN150
-
Pressure Rating: 5K
-
Body Material: Bronze
-
Disc Material: Bronze
-
Stem Material: Bronze
Applications
-
Marine water treatment systems
-
Shipboard water distribution networks
-
Industrial pressure management applications
-
Cooling water systems
-
Freshwater and seawater handling
-
Offshore platform water systems
Quality Assurance
-
Stringent Quality Control: Comprehensive inspection at all production stages
-
Marine Environment Optimized: Bronze construction for saltwater corrosion resistance
-
Reliable Performance: Engineered for long service life in demanding conditions
-
International Standards: Meets global marine and industrial requirements
Dimension Chart (IMPA Code Reference)
| IMPA Code | Model | L | D | C | No. | h | t | H | D2 |
|---|---|---|---|---|---|---|---|---|---|
| 750801 | 7363 5K050 | 180 | 130 | 105 | 4 | 15 | 16 | 285 | 125 |
| 750802 | 7363 5K065 | 190 | 155 | 130 | 4 | 15 | 18 | 330 | 140 |
| 750803 | 7363 5K080 | 200 | 180 | 145 | 4 | 19 | 18 | 380 | 160 |
| 750804 | 7363 5K100 | 230 | 200 | 165 | 8 | 19 | 20 | 430 | 180 |
| 750805 | 7363 5K125 | 250 | 235 | 200 | 8 | 19 | 20 | 495 | 200 |
| 750806 | 7363 5K150 | 170 | 265 | 230 | 8 | 19 | 22 | 560 | 224 |
The description/sizes may be different with goods, please check with us when order.
