Marine Bronze Angle Globe Valve | JIS F7349 & F7400 16K Rated for Marine & Offshore Applications
Product Overview
Our JIS F7349 marine bronze angle globe valve is engineered for precision flow control in demanding shipboard and offshore environments. Combining a durable cast steel body with bronze disc and brass stem, this valve meets JIS B2220 flange standards and delivers reliable performance in critical marine applications. Ideal for shipbuilding, vessel maintenance, and offshore platform piping systems requiring robust and corrosion-resistant fluid handling solutions.
Key Features & Benefits
-
Dual JIS Compliance: Manufactured to JIS F7349 and JIS F7400 standards for marine valves
-
Premium Material Combination: Cast steel body with bronze disc and brass stem for optimal corrosion resistance
-
16K Pressure Rating: Suitable for medium to high-pressure marine piping systems
-
JIS B2220 Flange Standard: Ensures perfect compatibility with marine piping networks
-
OEM Customization: Accepts custom branding and development from client specifications
-
Quality Materials: Carefully selected components meeting domestic and international standards
Technical Specifications
-
Standard: JIS F7349 & JIS F7400
-
Flange Standard: JIS B2220
-
Nominal Diameter: DN15 to DN40
-
Pressure Rating: 16K
-
Body Material: Cast Steel
-
Disc Material: Bronze
-
Stem Material: Brass
Applications
-
Shipboard cooling and water systems
-
Offshore platform fluid handling
-
Fuel and lubricating oil pipelines
-
Ballast and bilge management systems
-
General marine service applications
Quality Assurance
-
Rational Structure Design: Optimized for marine operational reliability
-
Aesthetic Appearance: Professional finish suitable for modern vessel installations
-
Material Flexibility: Customer-selectable materials available
-
International Standards Compliance: Meets global marine industry requirements
Dimension Chart (IMPA Code Reference)
| IMPA Code | Model | L | D | C | No. | h | t | H | D2 |
|---|---|---|---|---|---|---|---|---|---|
| 750531 | 7349 16K15 | 70 | 95 | 70 | 4 | 15 | 12 | 145 | 80 |
| 750532 | 7349 16K20 | 75 | 100 | 75 | 4 | 15 | 14 | 155 | 100 |
| 750533 | 7349 16K25 | 85 | 125 | 90 | 4 | 19 | 14 | 175 | 125 |
| 750534 | 7349 16K32 | 95 | 135 | 100 | 4 | 19 | 16 | 175 | 125 |
| 750535 | 7349 16K40 | 100 | 140 | 105 | 4 | 19 | 16 | 190 | 140 |
The description/sizes may be different with goods, please check with us when order.
