JIS 10K Bronze Globe Valve

JIS 10K Bronze Globe Valve – Class 150 Marine Brass Stop Valve for Ship Systems

Overview

Our JIS 10K Bronze Globe Valve is a high-performance marine-grade stop valve designed for precise flow control in ship piping systems. Manufactured to JIS 10K standard with premium bronze and brass construction, this marine brass globe valve offers exceptional corrosion resistance in seawater applications. Ideal for shipbuilding, ship repair, and offshore platform use, it provides reliable shut-off service in critical marine systems.

Key Features & Benefits

Marine-Grade Materials: Valve body manufactured from high-quality bronze (CAC401/BC6), with brass internals for superior seawater corrosion resistance
JIS 10K Pressure Rating: Designed to Japanese Industrial Standard 10K pressure class (approximately 150 psi) for marine applications
Class 150 Compatibility: Matches ANSI Class 150 pressure rating for international standardization
Precise Flow Control: Globe valve design provides excellent throttling capability and positive shut-off
Durable Construction: Reinforced cast iron handwheel for reliable operation in harsh marine environments
IACS Certification Available: Manufactured to meet ABS, BV, CCS, LR, RINA and other classification society standards
Customization Options: Material configurations and specifications can be tailored to customer requirements
Global Export Support: Professional export team with 24-hour technical response capability

Applications

Shipboard Cooling Water Systems
Marine Fresh Water Lines
Fuel Oil Service Systems
Lube Oil Transfer Lines
Bilge and Ballast Systems
Compressed Air Service
General Marine Service Applications
Offshore Platform Piping Systems

Technical Specifications

Body Material: Bronze
Bonnet Material: Brass
Disc Material: Brass
Stem Material: Brass
Handwheel: Cast Iron
Pressure Rating: JIS 10K (ANSI Class 150 equivalent)
Temperature Range: -20°C to 200°C
Nominal Diameter: 15mm (½”) to 100mm (4″)
End Connections: Flanged (JIS standard)
Media: Water, Oil, Air, Steam

Dimension Table (JIS 10K Standard)

DN	d	L	D	C	Bolt Holes	h	t	H	D2
15	15	60	80	60	4	12	8	77	50
20	20	70	85	65	4	15	9	88	65
25	25	80	95	75	4	19	10	99	65
32	32	100	115	90	4	19	11	110	80
40	40	100	120	95	4	19	12	126	80
50	50	120	130	105	4	19	13	139	100
65	65	140	155	130	4	19	13	154	125
80	80	160	180	145	8	19	16	178	140
100	100	180	210	175	8	19	16	200	140
