Japan Stock High-Holding Power Anchor

Certificate: CCS, GL, BV certificate, etc.
Delivery Time: 15 days
Place of Origin: China
Packing Details: Export standard packaging.

Category:

Japan Stock High-Holding Power Anchor: Certified Heavy-Duty Marine Anchoring Solution

Engineered for unparalleled performance, the Japan Stock Anchor is a premium Danforth-type anchor designed for the most demanding marine applications. Renowned for its exceptional holding-power-to-weight ratio of up to 1:12, this anchor delivers maximum seabed grip with minimal weight, making it an incredibly efficient and reliable choice.

Constructed from high-strength Cast Steel, it is built to withstand extreme forces and harsh oceanic environments. It serves as an ideal Stern Anchor for a wide range of vessels, including large boats, sailing vessels, workboats, and commercial ships, providing critical stability and secure mooring.

Key Features & Technical Specifications:

  • Superior Holding Power: Advanced Danforth fluke design ensures rapid penetration and a superior holding-power-to-weight ratio, offering secure anchorage even in challenging conditions.

  • Heavy-Duty Weight Range: Available from 500 KG to 8000 KG, catering to various vessel sizes and operational requirements.

  • Fully Certified Quality: Manufactured in compliance with leading international marine classification standards, including LR, ABS, DNV, GL, BV, NK, KR, IRS, and CCS.

  • Robust Construction: Made from high-grade Casting Steel for ultimate durability, impact resistance, and long service life.

  • Global Supply & Custom Delivery: We provide global logistics support and can deliver these certified anchors as per your specific project requirements.


Dimensional Data Table:

Nominal Weight (KG) Height – H (mm) Length – L (mm) Width – B (mm)
500 2000 2065 1350
700 2260 2335 1510
750 2310 2342 1560
1000 2550 2637 1700
1500 2890 2960 1950
2000 3160 3272 2140
3000 3630 3555 2650
3500 3810 3820 2570
4000 4000 4135 2920
5000 4310 4470 3140
6000 4580 4740 3330
7000 4820 4980 3530
8000 5040 5215 3620

The description/sizes may be different with goods, please check with us when order.
