Hydraulic Windlass Two-Chain Lifter for Marine and Industrial Applications
Our Hydraulic Windlass Two-Chain Lifter is a robust and versatile lifting solution designed to meet the demanding requirements of marine and industrial applications. This hydraulic lifting system is primarily composed of a hydraulic motor (available in both low-speed and high-speed variants), a hydraulic normally closed multi-plate brake, a planetary gearbox, an optional clutch, a reel, a support shaft, a frame, and an optional pressure rope. The hydraulic motor boasts high mechanical efficiency and substantial starting torque, ensuring reliable performance even under challenging conditions. It can be equipped with various flow distributors tailored to specific working conditions, and the valve group can be seamlessly integrated into the motor oil distributor based on user requirements, incorporating balancing valves, overload valves, high-pressure shuttle valves, speed-regulating valves, or other performance-enhancing valve groups.
The brake, planetary gearbox, and other critical components are directly installed within the reel, which, along with the support shaft and frame, is engineered to meet stringent mechanical standards. The overall structure is simple yet robust, offering ample strength and rigidity. This compact design results in a small, lightweight, and aesthetically pleasing unit that excels in safety, efficiency, and reliability. The Hydraulic Windlass Two-Chain Lifter is characterized by its large starting torque, excellent low-speed stability, low noise levels, and dependable operation.
Technical Specifications:
| Anchor Chain Type | Diameter (mm) | Working Load (KN) | Overloading (KN) | Loading Support (KN) | Nominal Speed (m/min) | Drum Load (KN) | Cable Capacity (m) | Mooring Line Load (KN) |
|---|---|---|---|---|---|---|---|---|
| AM2 | 17.5 | 13 | 14.6 | 19.5 | 9 | 80 | 10 | Φ11×100, 8 |
| AM2 | 19 | 15.3 | 17.2 | 23 | 9 | 95 | 25 | Φ13×100, 10 |
| AM2 | 20 | 17.9 | 20.0 | 26.9 | 9 | 110 | 20 | Φ13×100, 10 |
| AM2 | 22 | 20.6 | 23 | 30.9 | 9 | 126 | 20 | Φ15×100, 15 |
| AM2 | 24 | 24.5 | 27.4 | 36.8 | 9 | 149 | 20 | Φ15×100, 20 |
| AM3 | 26 | 28.7 | 32.1 | 43.1 | 9 | 175 | 20 | Φ22×120, 20 |
| AM3 | 28 | 33.3 | 37.2 | 50 | 9 | 202 | 20 | Φ22×120, 20 |
| AM3 | 30 | 38.3 | 42.8 | 57.5 | 9 | 231 | 30 | Φ22×120, 30 |
| AM3 | 32 | 43.5 | 48.6 | 65.3 | 9 | 261 | 30 | Φ20×120, 30 |
| AM3 | 34 | 49.1 | 54.9 | 73.3 | 9 | 294 | 40 | Φ20×120, 30 |
| AM3 | 36 | 55.1 | 61.6 | 82.7 | 9 | 329 | 30 | Φ20×120, 30 |
| AM3 | 38 | 61.4 | 68.9 | 92.1 | 9 | 365 | 40 | Φ22×150, 40 |
| AM3 | 40 | 58 | 76 | 102 | 9 | 402 | 40 | Φ22×150, 40 |
| AM3 | 42 | 75 | 83.8 | 112.5 | 9 | 442 | 40 | Φ22×150, 50 |
| AM3 | 44 | 82.3 | 92 | 123.5 | 9 | 483 | 50 | Φ26×200, 50 |
| AM3 | 46 | 89.9 | 100.5 | 134.9 | 9 | 526 | 50 | Φ26×200, 50 |
| AM3 | 48 | 97.9 | 109.4 | 146.9 | 9 | 570 | 60 | Φ26×200, 50 |
| AM3 | 50 | 106.3 | 118.8 | 159.5 | 9 | 617 | 80 | Φ26×200, 50 |
Frequently Asked Questions (FAQs):
- Q: What makes the Hydraulic Windlass Two-Chain Lifter suitable for marine applications?
- A: The Hydraulic Windlass Two-Chain Lifter is designed with high mechanical efficiency, substantial starting torque, and excellent low-speed stability, making it ideal for the demanding conditions encountered in marine environments. Its robust construction ensures reliable performance even in harsh weather and sea conditions.
- Q: Can the Hydraulic Windlass Two-Chain Lifter be customized to meet specific operational requirements?
- A: Yes, the Hydraulic Windlass Two-Chain Lifter can be tailored to meet specific operational needs. It offers various options for hydraulic motors, flow distributors, and valve groups, allowing for customization based on working conditions and user preferences.
- Q: What safety features are incorporated into the Hydraulic Windlass Two-Chain Lifter?
- A: The Hydraulic Windlass Two-Chain Lifter includes a hydraulic normally closed multi-plate brake and an optional clutch, ensuring safe and controlled operation. Additionally, the integration of overload valves and balancing valves enhances safety by preventing excessive loads and ensuring stable performance.
- Q: How does the compact design of the Hydraulic Windlass Two-Chain Lifter benefit users?
- A: The compact design of the Hydraulic Windlass Two-Chain Lifter results in a small, lightweight unit that is easy to install and maintain. Its aesthetic appeal, combined with its robust construction, makes it an ideal choice for applications where space is limited, and reliability is crucial.
- Q: What types of anchor chains are compatible with the Hydraulic Windlass Two-Chain Lifter?
- A: The Hydraulic Windlass Two-Chain Lifter is compatible with various anchor chain types, including AM2 and AM3, with diameters ranging from 17.5mm to 50mm. This versatility ensures that it can be used with a wide range of anchor chains, meeting diverse operational requirements.
