Hydraulic Thrusters – Compact & Cost-Effective Maneuvering Solution
Product Overview
The Hydraulic Thrusters is a highly efficient propulsion system that uses hydraulic power to drive the propeller directly, offering 360° steering capability for superior maneuverability. Designed for yachts, dredgers, and light-duty workboats, this system combines compact design, easy installation, and low operating costs.
Key Features & Benefits
✔ Hydraulic Drive System – Direct propeller drive for smooth, high-torque thrust
✔ 360° Azimuth Rotation – Full-directional control for precise maneuvering
✔ Compact & Lightweight – Space-saving design for small to medium vessels
✔ Low Maintenance – Simple mechanical structure reduces servicing needs
✔ Cost-Effective – Lower installation & operational costs vs. electric/diesel thrusters
Technical Specifications
| Parameter | Specification |
|---|---|
| Power Range | 60HP – 500HP |
| Drive Type | Hydraulic motor (direct drive) |
| Rotation | 360° continuous steering |
| Applications | Yachts, dredgers, workboats, small ferries |
| Certifications | ABS, BV, DNV, CCS (upon request) |
Parameters:
| Model | Dia of propeller (mm) | Power Rating (HP) | Thrust (t) |
| HSHP50 | 620 | 0-50 | 0-0.7 |
| HSHP100 | 830 | 50-100 | 1-1.4 |
| HSHP200 | 950 | 100-200 | 1.5-3.2 |
| HSHP300 | 1000 | 200-300 | 3.4-4.4 |
| HSHP400 | 1180 | 300-400 | 4.7-6.2 |
| HSHP500 | 1300 | 400-500 | 6.5-7.7 |
The description/sizes may be different with goods, please check with us when order.
