High Pressure Water Cooling Marine Air Compressor
Product Characteristics:
- Type: Single-row, vertical type, three-stage differential piston-style.
- Discharge capacity: 0.27 – 0.43 m³/min; Discharge pressure: 6.0 – 19.6 MPa.
- Compact structure, small size, light weight, and high pressure.
- Mainly used for defense area, starting the main engine of ships, and the work of underwater breathing for divers.
Main Specifications
| Model | Discharge capacity (m³/min) | Discharge Pressure (MPa) | Rotating Speed (r/min) | Motor Power (kW/HP) | Dimension (L×W×H) (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| 1-0.27/150 Horizontal unit | 0.27 | 14.7 | 970 | 7.5/10 | 1100×500×950 | 300 |
| 1-0.27/150 Vertical unit | 0.27 | 14.7 | 1000 | 7.5/10 | 555×585×940 | 210 |
| CZ-0.42/150 Horizontal unit | 0.42 | 14.7 | 1460 | 11/15 | 1100×500×950 | 330 |
| CZ-0.42/150 Vertical unit | 0.42 | 14.7 | 1500 | 11/15 | 620×650×1000 | 270 |
| CZ-0.43/60 Horizontal unit | 0.43 | 6.0 | 1460 | 11/15 | 1100×500×950 | 330 |
| CZ-0.43/60 Vertical unit | 0.43 | 6.0 | 1500 | 11/15 | 620×650×1000 | 270 |
| CZ-0.41/200 Horizontal unit | 0.41 | 19.6 | 1460 | 11/15 | 1100×520×950 | 350 |
Attention please: The description might be incorrect, please contact us for confirmation.
